Preserve, Protect and Defend

Our thoughts about government get intertwined with our images of the buildings that house its institutions. Architects know this, and in their designs, they often strive to evoke the key principles governments aspire to—permanence, stolidity, common-sense functionality, even grandeur. These buildings can touch our emotions. They can inspire us.

But no building lasts forever. When the time comes, talented individuals and enterprising companies have to step up and secure the integrity of these landmarks so they can survive to serve and inspire future generations.

The twin themes of this issue are government projects and historic renovation. Many of the projects you’ll see detailed on these pages would qualify in both categories, including three buildings that recently had iconic structures at their peaks meticulously restored. They include the copper pyramids on the North Carolina Legislative Building in Raleigh, North Carolina; the Saskatchewan Legislative Dome in Regina, Saskatchewan; and the Bradford County Courthouse Dome in Towanda, Pennsylvania.

The contractors involved in these projects conveyed the sense of responsibility that comes with keeping these one-of-a-kind structures functioning. But as they talked about the challenges they faced on these projects, it was the love of their jobs that kept coming through.

“We’re using natural, traditional building materials of stone, wood, copper and other noble metals,” said Philip Hoad of Empire Restoration Inc. in Scarborough, Ontario, as we talked about the Saskatchewan Dome project. “That’s what drives me to love the industry and my job—because it’s permanent, sustainable and it’s for future generations.”

Mike Tenoever of Century Slate in Durham, North Carolina, echoed that message when he talked about his company’s work on the North Carolina Legislative Building. “Our guys do this every single day, day in and day out,” he said. “It’s repetition, practice and love of restoration. Taking something so amazing and restoring it to the beauty it originally had—we all get a kick out of that.”

“You put in a hard day’s work and you’re proud to go home and know that what you’ve done is going to last not only your lifetime, but probably your kids’ lifetime, and maybe even your grandkids’ lifetime,” said Bill Burge of Charles F. Evans Roofing Company Inc. in Elmira, New York, as he detailed his company’s work on the Bradford County Courthouse.

Each of the roofing professionals I spoke with about these projects had the conscious goal of making sure the systems they installed might last another century. “We try to think of these slate and metal projects in terms of 100 years—that’s why we named our company Century Slate,” said Tenoever.

“This is the one thing that makes Charles F. Evans Company special to me: the fact that what we do from an architectural sheet metal standpoint, from a slate, copper, tile roof standpoint—these roofs will last 100, 150 years, and it is artwork,” Burge said.

“At the end of the day, why do we go to cities?” Hoad asked me. “We go to cities to look at their beautiful old buildings. We don’t generally go to look at their skyscrapers. It’s the old building that gets our minds and hearts working. When you go to a city and look at these old buildings intermingled with new buildings—that’s what gives a city life.”

Expert Crew Is Called in for Copper Roof Restoration Project

The dome on the Bradford County Courthouse was restored with copper panels during the first phase of a $3 million renovation project. Photos: Charles F. Evans Roofing Company Inc.

The octagonal dome atop the Bradford County Courthouse has been a fixture on the Towanda, Pennsylvania, skyline for more than 120 years. It now shines brightly after being restored with copper panels as part of a $3 million renovation project.

Built in the Classical and Renaissance revival styles in 1898, the four-story courthouse was placed on the National Registry of Historic Places in 1987. The dome’s original roof tiles were recently replaced as part of the project, which also included the complete restoration of the structure’s main roof.

The Charles F. Evans Company Inc., the union division of Evans Roofing Company Inc., headquartered in Elmira, New York, has a long history of successfully tackling projects with historical significance. C&D Waterproofing Corp., the general contractor on the project, reached out to the firm for support assessing the roofing portion of the project. The two companies teamed up on the project, with C&D Waterproofing handling the masonry restoration work and Charles F. Evans Company installing the roof systems.

The roofing work consisted of two phases. Phase One, which began in April of 2016, involved replacing the deteriorated terracotta tiles on the dome with soldered flat seam copper panels. Phase Two, which began in April of 2017, involved installing batten seam copper roofing on main structure and new copper flashings, gutters and downspouts.

Safety First

Construction Manager Bill Burge of Charles F. Evans Company was thrilled to be part of this historic project. Before

Originally completed in 1898, the courthouse was placed on the National Registry of Historic Places in 1987. The building’s main roof was removed and replaced with a copper batten seam roof after work on the dome was completed. Photos: Charles F. Evans Roofing Company Inc.

concentrating on the installation details, he knew the company would focus on the top priority. “Safety is number one,” says Burge. “Safety comes before profits. Safety comes before everything. We always want to make sure we have the right safety plan going into the job, and throughout the job, we are maintaining that plan and working that plan. We want our guys to go home to their families at the end of the day, so that’s key for us.”

Burge worked as a union carpenter for 10 years before joining the company more than seven years ago. He found he had an affinity for sheet metal work. “The craftsmanship and quality goes hand in hand with carpentry,” Burge says. “Everything starts with the carpentry. You have to have your base perfect; otherwise, everything from there on out doesn’t work. Sheet metal is a finished product, typically, especially in our business, so things have to be done right. Things have to be done to the highest standard of quality, because that’s what people see.”

The dome was designed to be a showpiece, and Field Superintendent Brian Babcock and his crew of qualified union sheet metal mechanics knew they would be held to an exacting standard. “The key to this project and every project is our talented mechanics in the field,” Burge says. “Charles F. Evans Company is nothing without this talent—they deserve all of the credit.”

Around the Dome

Phase One began with the removal of the tiles on the dome. “The ceramic tile was laid over open steel purlins,” Burge notes.

Charles F. Evans Roofing Company handled the roofing portion of the project, while C&D Waterproofing Corp. served as the general contractor and performed masonry restoration work. Photos: Charles F. Evans Roofing Company Inc.

“There was open framing with quarter-inch steel angle for the purlins, and each piece if tile was wired on. The removal process was fairly simple. You could actually lift up the bottom of the tile and snap it off.”

The removal work had to be done in sections and dried in every night. “One of the hardest things about this process was we had to install two layers of half-inch plywood over the steel purlins and anchor those down,” says Burge.

The plywood was attached to vertical two-by-fours, which were screwed into the purlins. The plywood was covered with one layer of Warrior 30-pound felt paper, Meadows Red Rosin Paper, and Grace Ultra High Temp underlayment in gutter areas.

The built-in gutter at the base of the dome was torn out and re-framed. The new gutter was wider and deeper according to the recommendation of Levine & Company Inc., the architect on the project. “We did everything to specification as Levine & Company drew it,” says Burge.

Once the cladding was completed on the gutter, the copper panels of the dome were installed. The 20-inch panels were made of 20-ounce, cold rolled copper, supplied by Revere Copper Products. Both the panels and cladding were fabricated in Charles F. Evans Company’s fabrication shop. The copper panels clip to each other and have a hem on four sides that clips

Custom flashing pieces were fabricated and installed where the copper roof panels met the base of the dome. Photos: Charles F. Evans Roofing Company Inc.

to the adjacent panel fastened to the deck. At the top of each panel, a hook clips off to the plywood, and the hook is covered by the panel directly above it.

Burge points out that the octagonal structure of the dome helped speed up the installation of the copper panels. “There are eight hips on the dome,” he notes. “Every section of the dome is like a piece of pie, basically, so we were able to start the panels in various locations. We didn’t have to start at one end and go around the dome. We could move around.”

Repairing the statue on the top of the dome was also part of the scope of work. “We soldered copper patches on any damage the statue had,” Burge says. “C&D Waterproofing completely cleaned and buffed the statue and applied a copper coating.”

Across the Roof

After the work on the dome was completed, work began on the main roof. The existing roof was removed down to the existing steel deck. The lower roof also had a built-in, copper-clad gutter that had to be removed and reconstructed. After

Scaffolding systems were constructed for both phases of the project. Shown here is part of the system installed around the lower roof, which featured planks and guardrails at the eave and rake edges. Photos: Charles F. Evans Roofing Company Inc.

the gutter was completed, work on the main roof began. “After we completely cleaned the metal decking, we had to install a layer of Grace Ultra High Temp underlayment,” Burge recalls. “We then installed two-by-four wood sleepers, 2 feet on center.”

Crews installed 1.5 inches of polyiso insulation between the two-by-fours, followed by another 1.5-inch layer of polyiso. Pieces of 5/8-inch plywood were then screwed down to the sleepers. The plywood received 30-pound felt, and the battens were installed 20 inches on center. The seams were completed using a custom-designed mechanical seamer manufactured by Roll Former Corp.

Installation of the 12,000 square feet of copper panels went smoothly, but where panels met the dome, details were tricky. “Everything is pitched, and the dome has eight different sections sitting right in the center of the structure,” Burge explains. “A lot of time and energy went into fabricating and installing custom flashing pieces at the base of the dome.”

The Safety Plan

A scaffolding system was the key to the safety plan for both phases of the project. “For Phase One, we had to remove a portion of the roofing system and put down some plywood on top of the existing roofing in order to build a scaffold to access the dome,” Burge says.

This photo shows the main roof before restoration work began. Photos: Charles F. Evans Roofing Company Inc.

Scaffolding was constructed to the eave edge of the copper dome, allowing the gutter to be removed. Ladders were used to access the dome and personal fall arrest systems were attached into HitchClips from Safety Anchor Fall Equipment, LLC, which served as individual anchor points. “We continued that process as we went up, using ladder jacks,” says Burge. “We continued with that plan, and never deviated.”

After Phase One was completed, the scaffolding was removed, and another scaffolding system was installed around the entire lower roof. Phase Two required planks and pre-engineered guardrails at the eave and rake edges. “Part of process of installing this roof included installing new safety anchors at various locations, and as we finished up, we were able to use those anchors as tie-off points,” Burge points out.

Phase Two is scheduled for completion in early November, and Burge has high praise for everyone involved with the project. “Levine & Co. Inc. is the architecture firm on the project,” he says. “We didn’t deter from any details developed. They drove this thing. We have worked with them on a great many projects in the past, and we have a great comfort level with them.”

Copper panels, cladding and details were fabricated in Charles F. Evans Company’s metal shop. Photos: Charles F. Evans Roofing Company Inc.

The masonry and roofing work had to be well coordinated. “C&D Masonry & Waterproofing progressed ahead of us with items that we needed to be done, and then came back behind us to mortar all of the counter flashings back into the dome,” Burge says. “They were right there with us every step of the way.”

Finding the right combination of workers for this project was crucial, according to Burge. “We had one of our best crews on this project for a reason,” he says. “This project was led by Brian Babcock of Sheet Metal Local 112, and he was essential in putting this whole thing together. He’s been with Charles F. Evans Company for 20 years, and his leadership and focus is the reason this project is going to be successful.”

Ornate sheet metal work is rare these days, but the art is not lost at Charles F. Evans Company. “We’ve been doing this work for 60-plus years,” Burge says. “This knowledge and this workmanship has been handed down generation after generation. We wouldn’t have taken on this project if we didn’t have the confidence in our employees that we do.”

Historic restoration projects are becoming an increasingly bigger chunk of the company’s portfolio, notes Burge. “We do a lot of work with older universities and businesses that have these types of buildings,” he says. “A lot of buildings need this type of work, and it’s a trade not everyone else has. This is a craft that takes years to master. We harness that, we build from within, and we bring in young guys and teach them how to do it the right way. We have a great mix of people ages 23 up to 60, and it’s learned, it’s taught, and it’s preached.”

Burge is hopeful the new roof will last at least as long as its predecessor. “This is the one thing that makes Charles F. Evans Company special to me: the fact that what we do from an architectural sheet metal standpoint, from a slate, copper, tile roof standpoint—these roofs will last 100, 150 years, and it is artwork,” he says. “The fact that you’re a part of something that’s been around since the turn of the last century—to me it doesn’t get any better than that.”

TEAM

Architect: Levine & Company Inc., Ardmore, Pennsylvania, Levineco.net
Construction Manager: C&D Waterproofing Corp., Bloomsburg, Pennsylvania, CDwaterproofingcorp.com
Roofing Contractor: Charles F. Evans Roofing Co. Inc., Elmira, New York, Evans-roofing.com

MATERIALS

Copper Supplier: Revere Copper Products, Reverecopper.com
Synthetic Underlayment: Grace Ultra High Temp, GCP Applied Technologies, GCPat.com
Mechanical Seamer: Roll Former Corp., Rollformercorp.com
Anchor Points: HitchClip, Safety Anchor Fall Equipment, LLC, Hitchclip.com

Restoring the Saskatchewan Legislative Dome Is a Labor of Love

The Saskatchewan Legislative Building in Regina was originally completed in 1912. The structure had undergone deterioration due to poor drainage around the dome, and a restoration project was initiated to repair the masonry and restore the copper dome. Photos: Ministry of Central Services, Government of Saskatchewan

“At the end of the day, why do we go to cities?” asks Philip Hoad. “We go to cities to look at their beautiful old buildings. We don’t generally go to look at their skyscrapers. It’s the old building that gets our minds and hearts working. When you go to a city and look at these old buildings intermingled with new buildings—that’s what gives a city life.”

Hoad is with Empire Restoration Inc., headquartered in Scarborough, Ontario, Canada. He’s been restoring historic buildings for some 30 years, and when he found out about the project to renovate the dome on the Saskatchewan Legislative Building, he knew it was a once-in-a-lifetime opportunity. “The architect put out a pre-qualification across Canada, and four firms were successful. We were one of them,” he remembers. “Then we ended up securing the tender bid. I’ll never forget it because I did the tender estimate just after a hernia operation in my dressing gown. It was really a project I won’t forget.”

The building was originally constructed in Regina, Saskatchewan, between 1908 and 1912, and it serves as the seat of government for the province and houses the legislative assembly. Designed by architects Edward and William Sutherland Maxwell of Montreal in a mix of English Renaissance and French Beaux-Arts styles, the building features ornate stone elements and unique decorative copper finishes that accent its iconic copper-clad dome. It is designated as a National Historic Site of Canada and a Provincial Heritage Property, and is subject to strict regulations regarding materials and methods of repair.

Work on the dome was carried out in a fully enclosed and heated temporary structure that allowed crews to continue throughout the winter months. Photos: Ministry of Central Services, Government of Saskatchewan

The structure has undergone some restoration work over the past 100 years, but in 2013, planning began for a conservation project designed to repair and restore the tower. The reasons for the project were twofold, according to Hoad. “First of all, the copper panels were blowing off, and somebody had re-secured them with face screws back in the ’60s or ’70s. But more importantly, the water was coming off the dome and damaging the stone below it. The dome was originally never designed with gutters, and then they later put gutters on, and these failed. So those were the two things that drove the project in the first place.”

Hoad knew the project would be challenging, but it he was confident that his company had the experience and passion to handle it. “These projects come along, for most of us, once in a lifetime,” he notes. “It’s the scale and the detail and the level of commitment that you need to restore an old building that sets us apart from, say, new construction. It’s not cookie-cutter. Everything is different, and you never know what you’re getting into—although with our experience, we’ve done so many old buildings we sort of know what we’re going to run into. All of the people who work for us love to work on these old buildings. It’s very satisfying at the end of it.”

The goals of the project were perfectly aligned with Hoad’s business philosophy. “When I start with an old building, I don’t want to change it,” he says. “It might look a little newer, but I want it to be the same as when we found it. I don’t want it to stand out as a brand-new building. We just want it to last another 100 years and to know that we’ve helped preserve it for future generations.”

The ornamental copper elements were restored and reset over the new copper panels. Photos: Ministry of Central Services, Government of Saskatchewan

Repairing the Substructure

Work on the dome was more complicated than initially thought. During the pre-construction condition survey and assessment, additional problems were discovered by the conservation architect, Spencer R. Higgins of Toronto. “Once the architect had done all his work and surveyed the building, they also realized the original woodwork was not quite up to snuff,” Hoad explains. “Basically, much of the original wood framing was made up of old pallets. It was quite remarkable. So structurally, we had to re-frame the hips, which we call the ribs. We completely removed the old pallet framing and re-framed it. We also tried to straighten the slight twist in dome, but it wasn’t easy to do since it was a poured concrete structure underneath.”

New ribs were constructed out of Douglas fir plywood using a CNC machine from 3-D architectural drawings to create templates. It was also necessary to remove and replace approximately 40 percent of deteriorated wood deck on the concrete dome, with both the interior and exterior surfaces of the concrete being repaired by the general contractor on the project, PCL Construction Management of Regina. “Re-framing the ribs was quite a challenge,” notes Hoad. “Once the concrete deck was repaired, we screwed new Douglas fir roof boards into the repaired concrete dome, added an air vapor barrier, Roxul insulation, wood nailers and an additional layer of Douglas fir roof boards, with housewrap and asphalt saturated roofing felt as the underlayment system for all the new copper roofing and cladding that would follow.”

Internally drained stainless-steel gutters were installed at the base of the dome. The gutters were lined with sheet lead. Photos: Ministry of Central Services, Government of Saskatchewan

After the masonry restoration was completed by RJW-Gem Campbell Stonemasons of Ottawa, Empire Restoration installed new gutters at the base of the dome. According to the architect’s design, heavy stainless-steel plate gutters were formed and then lined with sheet lead. Projecting stone cornice ledges were also covered in sheet lead.

Restoring the Copper Dome

The existing 16-ounce copper panels were all removed, and they were replaced with new 20-ounce panels recreated to match the original sizes and profiles. More than 20,000 square feet of copper panels were custom fabricated and installed. Great care was taken to carefully remove and restore decorative elements, including the copper garlands.

Decorative elements that could be saved were installed on new brass armatures. The dome is topped by a cupola and lantern, which were carefully restored. “The mantel on the very top, we didn’t strip that off,” Hoad notes. “We just replaced and repaired selective components, so that’s why you have a mix of old and new.”

Logistics at the job site were well coordinated. “Access was quite remarkable because PCL had erected a steel frame onto which we erected scaffolding, so the dome was right there in front of us,” Hoad notes.

Cornice sections were restored, and extensive sheet lead flashings were installed over stone cornices and ledges. Photos: Ministry of Central Services, Government of Saskatchewan

When working on the dome itself, crew members had to be tied off with personal fall arrest systems, as it was possible to slip through gaps between the scaffold decks and the dome roof surface. Weather was not an issue, as the steel frame structure was totally enclosed with a heavy-duty insulated tarp system. “We had our own ventilation system, we had a heating system, we had electricity up there, we had pneumatic power—we basically had everything up there. PCL had it well set up for the various trades. There was a large crane on site to hoist all our materials up.”

Hoad cites the sheer size of the project as one of his greatest concerns. “The biggest challenge was just the scale of the project, being able to produce the amount of work necessary and get the job done in the prescribed time,” he says. “It was a lot of the same thing, albeit with some very complicated detailing. We had multiple skill sets on the site dealing with multiple materials and details.”

The project has won numerous awards, including a 2017 North American Copper in Architecture Award from the Copper Development Association. Hoad is proud of his company’s role in the project but relieved it is completed. “During it, I was at times tearing my hair out,” he recalls. “It was a very high-pressure project that lasted a long time. It was three or four days a week of constant men, materials, equipment, meetings, details, changes, extras, credits. From start to finish, it was two years of my life.”

The cupola and lantern at the top of the dome were repaired in situ. Photos: Ministry of Central Services, Government of Saskatchewan

Despite the pressure, Hoad found the work extremely satisfying. “What we are doing is permanent and built to last for future generations,” he says. “We’re using natural, traditional building materials of stone, wood, copper and other noble metals. That’s what drives me to love the industry and my job—because it’s permanent, sustainable and it’s for future generations.”

After all, it’s often the roof and flashings that play one of the most critical roles in fighting the elements of weather, notes Hoad. “Roofing and sheet metal deficiencies is where much of building damage and deterioration starts,” he says. “You can repair a masonry wall, but if you don’t stop it getting saturated, it’ll just deteriorate again in another few years. Regina was a good example of that. We’ve now provided great protection to these beautiful stone elements, allowing them to last another 100 years.”

TEAM

Conservation Architect: Spencer R. Higgins, Architect Incorporated, Toronto, Ontario, Higginsarchitect.com
General Contractor: PCL Construction Management, Regina, Saskatchewan, PCL.com
Sheet Metal Contractor: Empire Restoration Inc., Scarborough, Ontario, EmpireRestoration.com
Masonry Contractor: RJW-Gem Campbell Stonemasons Inc., Ottawa, Ontario, RJWgem.com

MATERIALS

Copper: 20-ounce copper sheet metal
Wood Framing: Douglas fir
Insulation: Rockwool Rigid Insulation, Roxul, Roxul.com

Orlando Airport Project Necessitates Custom Fabrication, Precise Installation



Work on the first phase of the Orlando International Airport expansion project includes the South Airport Intermodal Terminal Facility and APM Complex, which features a standing seam metal roof

Architectural Sheet Metal Inc. has been in servicing the Orlando area for more than 23 years, specializing in commercial metal roofs and wall systems, primarily new construction. When Matthew Leonard, the company’s vice president, found out that the Orlando International Airport was proposing a new terminal project with a metal roof, he jumped at the chance to submit a bid.

He wanted to land the job because it would be the largest project the company has ever tackled, and one of its most prominent. He also wanted it for another reason—he knew he’d see it every time he drove to the airport. “For many years now, we’ve specialized in standing seam metal roofs. It’s our bread and butter,” he says. “We’ve done lots of schools, government building, military bases. It’s just something we enjoy doing. When this project came around, right here in our backyard, we knew we wanted to take it on. It’s larger than anything we’ve ever done, but it’s our specialty.”

The South Airport Intermodal Terminal Facility and APM Complex is a new construction project that coordinates mass transit for the airport, including regional rail systems and the Automated People Mover (APM). It’s part of the first phase of an ambitious $2 billion plan to almost double the size of the airport.

Architectural Sheet Metal installed the Berridge standing seam metal roof system, as well as internal aluminum gutters and a custom-fabricated aluminum bullnose that runs along the perimeter of the roof

The building encompasses approximately 200,000 square feet, and the structure is primarily covered with a standing seam metal roof. The scope of work for Architectural Sheet Metal included installing the metal roof system and internal aluminum gutters. It also included custom fabrication and installation of an aluminum bullnose that runs along the perimeter of the roof. “Every roof is radiused, and some sections have compound double raiduses,” Leonard notes. “The trickiest part of the project is probably the bullnose because all of the gable ends of the roof are radiused, and the large bullnose has to be welded on in 30-foot sections.”

Another tricky thing about the project is that the work was divided into two different contracts with two different construction managers. On one side of the building, which houses the monorail and parking garage, the project is overseen by Hensel Phelps, and on the other side, which handles the train lines, the construction is overseen by a Turner-Kiewit joint venture. The dividing point is a building expansion joint that runs across the middle of the roof. “We’re one of very few subcontractors out here that has a contract with both of the construction managers,” Leonard says. “They both have their own agendas, their own timelines, and their own completion dates, and it was a delicate balancing act working with the two of them.”

Installing the Roof

The roof system was designed to unify the elements of the structure and tie the building together. Some sections of the roof cover the building, while others serve as canopies, so there are two types of metal deck on the building. “The area we call the spine has a 3-inch-thick acoustical deck,” Leonard explains. “That was interesting because before we could put our 6 inches of polyiso on, we had to install batten insulation in the flutes. The acoustical decking is perforated, so you can see through it. That’s a little different, when you’re so high up. It spooked the guys at first to be able to see right through it.”

Crews dried in the entire roof with a waterproofing underlayment from MFM Building Products specifically designed for high-temperature applications.

The other sections were comprised of standard type B metal deck. Sections covering the interior were insulated, while canopy sections were covered with 5/8-inch DensDeck from Georgia-Pacific.

Crews from Architectural Sheet Metal dried in the entire roof with a peel-and-stick waterproofing underlayment from MFM Building Products specifically designed for high-temperature applications, MFM Ultra-HT. “It’s easy to install,” notes Leonard. “That’s our go-to underlayment for metal projects.”

After the underlayment was applied, the welded aluminum gutters were installed. “The longest piece was 78 feet,” says Leonard. “We fabricated the sections, water-tested them and shipped them out. We used a crane to lift them to the roof.”

The roof system was supplied by Berridge Manufacturing, and the 24-gauge galvalume metal panels were roll formed at the site. “Berridge has a ZEE-Lock double-lock standing seam panel,” Leonard says. “We own one of their portable roll formers, and we have it on site here. We pick it up with a crane, and lift it up to the edge of the roof, and we actually roll form our largest panels straight out to the roof. The guys just catch the panels as they come out of the roll former.”

Metal roof panels were roll formed at the site. For most roof sections, the roll former was hoisted by a crane, to the edge of the roof, and crew members stacked the panels as they come out of the roll former.

Panels were stacked in piles of 10 for installation. There were 12 different roof surfaces, so as the roll forming crew moved along, other crews would start installing the panels. “Every stack was tied down with strapping to ensure that it wasn’t susceptible to wind,” Leonard points out. “With a hurricane in the forecast, we were very careful about that.”

The panels in the spine area had a tighter radius, so those panels were formed on the ground using separate curving machine. Lining up the panels perfectly was critical. “With a radiused roof, it’s sometimes harder to find things to measure off to ensure your panels are straight. This panel is a left-to-right system. It’s a male-female overlay with a continuous clip that Berridge manufactures. The panels are hand-crimped together, and then you do the first and second stage of the double-lock panels with an electric seamer. You just turn it on and it goes up and over.”

Details, Details

Fall protection posts were installed during the framing process, which helped with safety planning but posed problems when it came to detailing. “It’s nice to have permanent fall protection points to tie into, as everyone had to be 100 percent tied off, but there are close to 200 fall protection posts on the project that we had to cut around and flash,” Leonard says. “I’ve never seen so many posts on a roof like that.”

The aluminum bullnose was constructed after precise measurements were taken at the site. After they were custom painted to match the roof, the 30-foot sections were lifted into place and installed.

Because the posts were tied into the structural steel and couldn’t be moved, the company designed and manufactured a welded aluminum flashing detail to ensure they all looked the same no matter where they landed in the panel profile. “We set up a welded aluminum flashing that should last forever, and it’s welded, so it shouldn’t leak. We try to go above and beyond in our flashing details.”

Leonard points to his company’s fabrication experience as a key to its strength. “We try to be more than just a roofing company,” he says. “We try to be a custom metal fabrication company that fabricates the panels to precise specifications determined by the site. We custom fabricate metal and then, as roofers, we install it. We like to have that double whammy. Not many people have that ability to do both.”

The company’s expertise came in handy on the bullnose. “The bullnose was originally bid as 22-gauge metal,” he says. “We looked at it and we didn’t like it. It’s a large, 9-inch radius, and we felt the thin, light-gauge metal would shake in the wind. Every 10 feet would be a lap joint with caulk, which would be susceptible to wind damage. We came up with the idea of using a welded piece of .080 aluminum. Once it was approved, we purchased a 100-ton press brake with a custom die to fabricate this bullnose.”

The bullnose was constructed from precise measurements taken at the site. “We took the radius off of the building and created jigs in our warehouse,” Leonard explains. “We welded pieces together in 30-foot sections, and we shipped them to a local painter who coated them with baked-on Kynar to match the roof.”

The bullnose was designed to hook into the gutter strap and wrap around onto the fascia, where it is screwed into the framing. In areas where there is no gutter, sections of the bullnose are equipped with a larger flange with an S-hook built into it to attach it to the roof. Corner pieces tie it all together.

Watching Out for Irma

Dealing with two different GCs was challenging, in part due to changes in the schedule. “Originally, we were supposed to finish one side first and then start the other side, but both phases of the project ended up starting around the same time,” says Leonard. “This doubled the manpower we needed on the job.”

Photos: Aerial Innovations

For changes like the bullnose, Architectural Sheet Metal had to make sure RFIs were submitted and approved by both sides. “Sometimes it was hard to keep track of who we submitted it to, but it worked to our benefit at times. Once it was approved by one side, it was easily approved by the other.”

The schedule had the crews working in hurricane season, and precautions were taken to make sure the job site was prepared for high winds. “When Hurricane Irma was approaching, I checked every single weather update every day until it made landfall,” Leonard recalls. “It hit on a Monday, and a full week ahead of that we were cleaning the roofs and preparing the gutters. We removed all debris on the jobsite because any trash on the roof could clog the downspouts. We added more and more men to the process throughout the week, and we shut the jobsite down on Wednesday. We took all of the material we had, stacked it, bundled it together, and we were able to move it all inside the building. We were pretty well complete on the Hensel-Phelps side, and Turner Kiewit brought in 40-foot Conex boxes for us to put our material in and secure it. They tried really hard to make sure the jobsite was secure.”

As the storm progressed, it deviated from the projected path, and no one could be certain which direction the winds might be coming from. “We just had to start battening everything down,” Leonard recalls.

Photos: Architectural Sheet Metal Inc.

Stacks of panels on the roof that were not yet installed were strapped every 2 feet on center. The entire state was in emergency mode, making things difficult. “For four or five days before the storm even hit, we couldn’t find water, rope and extension cords. Grocery stores were running out of supplies. Gas stations were running out of gas.”

After the storm passed, Leonard breathed a sigh of relief. The roof wasn’t damaged. The panels that had already been installed were in great shape, and the uninstalled panels weren’t harmed.

Elements like the weather are beyond anyone’s control, and Leonard notes his company tries to control as many variables as it can. “We have full control over the actual fabrication of the material and the quality of it,” he says. “When I call something in, I talk to our guy who works with me. Our company oversees it. Every morning I stop by the shop and follow up on the process on the way to the job site. We install it. I can make sure everything is OK.”

The project is nearing completion, and Leonard can’t wait to finish a landmark project he’ll see every time he makes a trip to the airport. “You can’t miss it,” he says. “It’s huge.”

TEAM

Architect: HKS Architects, Orlando, Florida, HKSinc.com
General Contractors: Hensel Phelps, Greeley, Colorado, HenselPhelps.com; and a joint venture between Turner Construction, Orlando, Florida, Turnerconstruction.com, and Kiewit, Sunrise, Florida, Kiewit.com
Metal Roofing Contractor: Architectural Sheet Metal Inc., Orlando, Florida, ASMfl.com

MATERIALS

Standing Seam Metal Roof: Berridge Zee-Lock Double-Lock, Zinc-Cote, Berridge Manufacturing, Berridge.com
Underlayment: MFM Ultra-HT Wind & Water Seal, MFM Building Products, MFMbp.com
Cover Board: DensDeck, Georgia-Pacific, Buildgp.com

North Carolina Legislative Building Restoration Poses Unique Challenges

The North Carolina State Legislative Building was the site of a renovation project that included asbestos abatement in the interior and a complete restoration of the building’s roof systems.

The North Carolina State Legislative Building was the site of a renovation project that included asbestos abatement in the interior and a complete restoration of the building’s roof systems. Photos: SkySite Images

Some of the variables that can make a project difficult include a variety of complex, interconnected systems, unique design elements, and a tight schedule. These challenges are heightened on a highly visible, historic building, where the goal of keeping the design historically accurate must be balanced with making improvements to the structure and functionality of the systems. All of these elements and more were in play during the restoration of the one-of-a-kind roof on the North Carolina State Legislative Building in Raleigh, North Carolina. It took a talented team of design, engineering, and roofing professionals to bring the project to a successful conclusion.

Originally designed by architect Edward Durell Stone, the building has been the home of the state legislature since 1963, but water intrusion under its copper pyramids and at windows and doors on the promenade level precipitated a complete restoration project. Renovation work conducted in 2016 and 2017 included asbestos abatement in the interior and a complete restoration of the building’s roof systems.

The roofing phase of the project included removing and replacing the metal roof systems on the five copper-clad pyramids, as well as re-roofing the low-slope sections adjacent to the pyramids with a two-ply modified bitumen system. A liquid-applied waterproofing system was installed in the planter areas and under the pavers in the promenade section. The project also involved the removal and replacement of windows, doors, and skylights, as well as repairing and coating the concrete surfaces at the perimeter of the roof.

The design of the quilted flat lock copper panel system involved 17 different panel profiles. A false batten was added after the panels were in place.

The design of the quilted flat lock copper panel system involved 17 different panel profiles. A false batten was added after the panels were in place. Photos: SkySite Images

Companies involved in the project included Raymond Engineering, headquartered in Raleigh, North Carolina, which provided engineering and architectural services; Owens Roofing Inc., also located in Raleigh, which served as the general contractor on the roofing phase of the project and installed the low-slope systems; and The Century Slate Company, headquartered in Durham, North Carolina, which removed and replaced the copper roofs on the five pyramids.

Some of the key players in the project shared their insights with Roofing, including John Willers, a senior engineer with Raymond Engineering; Bert Owens, president of Owens Roofing; and Mike Tenoever, president of Century Slate.

“This is an iconic state building with a unique roof system which the owner and designer required to be aesthetically replicated,” Tenoever notes. “At the same time, some functionality and technical improvements were incorporated. This is a very high-profile project with a lot of complexity, particularly given the schedule. There were a lot of details compressed into a very short period of time.”

Design and Pre-Construction

Raymond Engineering conducted testing on the existing roofs and specified systems designed to match the originals and provide some necessary improvements, including added insulation and ventilation under the pyramids. Willers worked closely with Jason Mobraten, the senior architect on the project. “We provided the engineering and architectural services, beginning with design and then assisting with bidding and managing the construction phase of this project,” says Willers. “We engineered the copper roof, all of the detailing for the modified asphalt roof, and the detailing for the drainage, the pavers, and the sealants for the promenade.”

Crews from Owens Roofing removed the existing plants, media and drainage system from four 42-foot-by-42-foot fixed planters with skylights. After the substrate was cleaned and primed, a liquid-applied waterproofing system was installed.

Crews from Owens Roofing removed the existing plants, media and drainage system from four 42-foot-by-42-foot fixed planters with skylights. After the substrate was cleaned and primed, a liquid-applied waterproofing system was installed. Photos: SkySite Images

The schedule was an obvious challenge, as the majority of the work had to be completed while the legislature was in recess, and there were substantial financial penalties that would come into play if the work was not completed on time. “The client also required that the asbestos abatement be completed before re-roofing the copper-clad pyramids to avoid the risk of dislodging the asbestos-containing textured ceiling finish. However, doing the work in two phases allowed the asbestos contractor to get started while the rest of the job was designed and bid,” Willers states.

The building houses legislators’ offices, and it was open and occupied during construction, with the exception of the areas undergoing asbestos abatement. The schedule had to be carefully adjusted as the job progressed. “In addition to our role in monitoring the technical aspects of the construction, we closely monitored the construction phasing and sequencing, as it was directly driven by the schedule of the state legislature,” Willers notes. “We had to take a lot of care in developing the schedule and monitoring it.”

Willers and Mobraten knew that the details on this project would be crucial. “There were previously some issues where the copper and the low-slope membrane roofs met,” Willers says. “We detailed that very carefully so that we had redundancy in keeping that watertight.”

Extensive mock-ups of the copper pyramids were constructed and tested to ensure the quilted pattern could be exactly replicated while avoiding the leaks that plagued the existing structure.

Photos: SkySite Images

Photos: SkySite Images

As designers looked for ways to improve construction, they explored the design and construction of the quilted panels. “From a design standpoint, we wondered why we had this odd diamond-shaped pattern,” Willers recalls. “After we played with the dimensions a bit, we realized that if you fly over the building, from above all of those diamond sections look like squares.”

The key was to replicate the design with its false battens while avoiding leaks. “We were concerned about how to detail out the joining of the copper sheets that formed the diamond-shaped panels,” Willers says. “What had been done was susceptible to windblown rain getting in. We did two things differently: the little clips that supported these battens were secured by forming the clips with hooks that would be integral with the single-locked seams and soldering the clips to the top surface of the copper panels. Previously they were held in place by pop rivets, which went through the copper.”

The Secrets of the Pyramids

Century Slate was well prepared to tackle the copper roofing on the project. The company has been in business more than 20 years, and it specializes in historic restoration projects including slate, tile, wood, copper and other historical metals.

Crews from Century Slate removed the existing copper panels. The copper was salvaged and recycled.

Crews from Century Slate removed the existing copper panels. The copper was salvaged and recycled. Photos: SkySite Images

Tenoever knew the design of the original quilted flat lock copper panel system needed to be replicated exactly. “There were 17 different panel profiles, each within a very particular location within the roof’s quilted pattern,” Tenoever notes. “Proper placement of each different profile was essential to the whole system working correctly and looking like the original.”

The first step was to remove the existing copper roofs. “We tore off the entire system down to the deck,” Tenoever explains. “We then installed a semi permeable a vapor barrier, insulation, and a vapor retarder.”

Along with added insulation and Carlisle WIP 300HT self-adhering underlayment, crews also installed a vented nail base from Hunter Panels. “The Hunter Cool-Vent is a vented nail base that gets screwed down,” Tenoever says. “The goal was to have a breathable air cavity. All of the hip caps are actually vented to allow the air to get out.”

With the addition of the insulation and nail base, the roof was built up approximately 6 inches from the previous configuration. This added height necessitated changes in the custom flashing at the base of the pyramids but did not change the configuration of the copper panels.

In all, 22,500 square feet of copper panels fabricated by K&M Sheet Metal in Durham were installed. Each of the 17 different panels was labeled with a letter code. “When they were out at the site, we could just grab an A panel or a B panel, as needed, and bring them to that layout,” Tenoever explains. “Four of the pyramids were the same, and the center one was different, as that was the one that had skylights built into it.”

The areas between the pyramids were covered with a two-ply modified bitumen roofing system. Photos: SkySite Images

The panels feature flat-lock clips that were screwed down to the nail base. “It’s a typical flat seam panel system, and the panels interlock together,” says Tenoever. “You can see the batten panel above it, which is an aesthetic feature. The battens and the clips that held them were amazingly intricate, for what they were. They were cut out with a CNC machine and soldered onto the copper panels prior to installation. Later we came back and installed the batten system over the top.”

Century Slate built new curbs in the center pyramid for the new skylights, which were manufactured by Wasco. “The skylights were one of the last things to go on,” says Tenoever. “They were custom made because even though they look square, there isn’t a square angle on them.”

Custom copper flashings were installed at the bases. “One of the trickier parts for us probably would have been the tie-in of the modified roof, because Owens Roofing had to do their bit, and we were also replacing all of the wood blocking and everything all along the bottom edge before we could put our flashing on,” Tenoever recalls. “It took a lot of coordination between the two trades, but it all worked out.”

The Low-Slope Roof Systems

Owens Roofing served as the general contractor on the project and installed the low-slope roof systems. The company was established in 1986 in Raleigh, and focuses on commercial and institutional buildings, almost exclusively re-roofing. Much of its work is on historic buildings, so Owens was confident he could execute the project and complete it on schedule.

A scaffolding system offered secure roof access, but material had to be loaded and removed from one access point, so logistics had to be carefully mapped out.

A scaffolding system offered secure roof access, but material had to be loaded and removed from one access point, so logistics had to be carefully mapped out. Photos: SkySite Images

Crews from Owens Roofing installed 18,900 square feet of modified bitumen roofing from Soprema over concrete decks, including the areas between the pyramids. Tapered polyiso and half-inch DEXcell cover board from National Gypsum were installed using Duotack adhesive, followed by the two plies of modified bitumen membrane.

A liquid waterproofing system from Sika was specified for the large planter areas. Crews from Owens Roofing removed the existing plants, media and drainage system from four 42-foot-by-42-foot fixed planters with skylights. After the substrate had been cleaned and primed, the Sika RoofPro system was installed.

“Once it’s cleaned and primed, it’s pretty simple,” says Owens. “The product is one part, and you don’t even have to mix it. We applied it with rollers on this project. You embed fabric sheets in the system and then topcoat it. It was a cold-weather job, but fortunately we caught a break last winter in that it wasn’t as cold as usual, and we didn’t miss as much time as we might have.”

The 30,000-square-foot promenade section was originally covered by white granite pavers native to North Carolina. The old pavers were removed and replaced over a new roof system, which was comprised of modified bitumen sheets beneath the liquid-applied waterproofing system. “The concrete deck was primed and a modified bitumen base ply heat welded to the deck,” Owens explains. “This surface was primed in preparation for the Roof Pro system, which was then installed.”

Innovative Roof Services of Raleigh was called in to conduct a high-voltage electrical testing to ensure there were no voids in the system before the pavers were re-installed. The pavers had originally been set in a bed of mortar, and they had to be removed and cleaned, which revealed a problem. “When we took the pavers up, we found out that they ranged between 1-1/8 and 1-3/4 inches thick,” Owens notes. “That wasn’t a problem when they were set in a bed of mortar, but over extruded polystyrene, they would have been all up and down. We put in a change order and had the pavers set in a bed of sand on top of one layer polystyrene.” The sand was adjusted by hand to ensure the pavers were level. New pavers were added to replace those broken over the years.

On the roof’s concrete eyebrows, damaged areas of concrete were repaired, joints were sealed, and a cold-applied waterproofing system from Sika Sarnafil was used to cover 8,800 square feet of concrete.

Numerous Challenges

Important considerations on the project included safety and logistics, as well as the tight schedule. Safety was paramount, and a third-party safety monitor was on the site to ensure the safety plan was designed and executed properly. During the time between when the original skylights were removed and when their replacements installed, the voids in the roof deck needed to be cordoned off and covered according to OSHA regulations. Personal fall arrest systems were used on the pyramids and outside of the safety perimeter, which was marked with flags. “With the promenade, you had a wide concrete eyebrow, so it made it easier to set up the safety lines and keep everyone safely away from the edge,” Owens notes.

This aerial photo taken before the restoration project shows the copper roofs with their green patina. Photos: SkySite Images

“Safety is a key concern as on all jobs, but this one in particular was highly visible out the windows of the nearby Department of Labor,” Owens continues. “We were paid a courtesy visit and agreed with them that an on-site safety meeting conducted by their personnel might be useful. The owner allowed us use of one of their auditoriums and we had a very productive half-day meeting for all trades. Every week we had a meeting with a state construction monitor.”

A scaffolding system was set up that offered secure roof access, but there was only one point for loading and unloading material, so logistics at the site were a concern. “We had to use wheelbarrows and roof carts to transport materials back and forth to the scaffolding tower,” Tenoever notes. “Between the removal of the original roof and the installation of the multiple layers of the new roof system, over 150,000 square feet of roofing materials were moved by hand over an average distance of approximately 200 feet.”

Loading and unloading added another wrinkle to the complicated schedule. “The schedule was based on when the legislature was scheduled to come back to town—not how long the job was supposed to take,” Owens says. “We were all concerned with the ambitious time frame and $1,000 a day liquidated damages included with this job.”

Willers cited excellent communication as one of the keys to completing the project on time. “Fortunately, the project managers for the general contractor and other trades were highly organized individuals,” Willers says. “Regular site meetings were detailed and thorough. Although setbacks did occur, communication kept the ball rolling.”

The roof system on the building’s iconic copper clad pyramids was removed and carefully recreated, matching the original design while adding a vented cavity and increasing the thermal insulation. Photos: SkySite Images

A Unique Experience

Copper removed from the existing roof was salvaged and recycled, notes Willers, with the exception of a few pieces that

were cut into the shape of the state of North Carolina to serve as mementos of the unique project. “We’re very proud of the design and the outcome—and the assistance we got from all of the contractors involved,” Willers says. “We had some pretty heavy rains after the project was completed, including some high winds, and there were no leaks.”

Tenoever also looks back on the project with pride. “A one-of-a-kind roof system was custom built and delivered on schedule and with the owner and designer’s praises,” he says. “Taking something so amazing and restoring it to the beauty it originally had—we all get a kick out of that.”

TEAM

Design and Engineering Services: Raymond Engineering, Raleigh, North Carolina, RaymondLLC.com
General Contractor: Owens Roofing Inc., Raleigh, North Carolina
Metal Roofing Contractor: The Century Slate Company, Durham, North Carolina, CenturySlate.com
Leak Testing: Innovative Roof Services, LLC, Raleigh, North Carolina, IRS-LLC.net

MATERIALS

Metal Roof System
Copper: 20-ounce copper sheet metal
Vented Nail Base: Hunter Cool-Vent, Hunter Panels, HunterPanels.com
Underlayment: Carlisle WIP 300HT, Carlisle, Carlislewipproducts.com
Skylights: Wasco Skylights, Wascoskylights.com

Modified Bitumen Membrane Roof System

Membrane: Sopralene Flam 180 and Sopralene Flam 180 FR GR, Soprema, Soprema.us
Adhesive: Duotack, Soprema
Insulation: Sopra-Iso, Soprema
Cover Board: DEXcell, National Gypsum, NationalGypsum.com

Waterproofing System

Liquid Applied Membrane: RoofPro 641, Sika Corp., USA.Sika.com
Reinforcing Fabric: Reemat, Sika Corp.
Primer: Sikalastic EP Primer/Sealer
Extruded Polystyrene Insulation: Foamular 604, Owens Corning, OwensCorning.com

Restoring Natural Slate Roof Takes Expert Craftsmanship

Photos: Charles F. Evans Company Inc.

When it came time to replace the roof on Howard W. Jones Hall, Youngstown State University wanted to closely re-create the original graduated natural slate roof. Photos: Charles F. Evans Company Inc.

Even slate roofs have to be replaced sometime.

Howard W. Jones Hall is one of the oldest buildings on the campus of Youngstown State University in Youngstown, Ohio. The limestone structure with its twin towers is an iconic structure, and when the original slate roof finally deteriorated, the university wanted to keep the stately look of natural slate on the building’s exterior.

Charles F. Evans Company Inc. of Elmira, N.Y., was awarded the Jones Hall restoration job in early 2017 and named 37-year veteran Ken Dennison as the project manager. “We seem to excel in doing difficult projects, including specialty systems of slate, tile, and architectural sheet metal,” Dennison says. “We emphasize quality workmanship and uncompromising customer satisfaction. We also emphasize safety, and currently we are the only roofing contractor to be an approved OSHA VPP mobile Mobile Workforce STAR contractor.”

The university wanted to replicate the existing 6,500-square-foot graduated slate roof with random widths, and slate roofing tiles in the same color and size range were chosen. The scope of work included repairing the existing masonry and installing copper gutters, valleys and flashings.

Going Old School

The first step was removing the old slates, which proved a tough task. “We had to remove them almost one by one,” recalls Dennison.

Copper details were custom fabricated for counterflashing and step flashing.

Copper details were custom fabricated for counterflashing and step flashing. Photos: Charles F. Evans Company Inc.

The existing wood plank deck was in very good shape, and Carlisle Water & Ice Protection self-adhering underlayment was installed at the eaves, valleys and rakes. It was also applied around all of the details. Then two layers of 30-pound felt were tacked into place with plastic-capped nails.

Natural hand-split roofing slate was delivered pre-cut and pre-punched by Evergreen Slate Co., located in upstate New York. The slates were mixed to ensure proper color distribution and arranged in piles for installation on the site. Once the underlayment was in place, the slate was installed just as it might have been a century ago. “We used copper nails,” Dennison notes. “Everything was nailed by hand—two nails per slate.”

The installation called for a 3-inch head lap. “With random slate, you don’t need to put any vertical lines in, because nothing is going to line up vertically,” Dennison explains. “Every side lap has to be at least 3 inches, but there is no set pattern for the widths—we just mix them up. That’s why they use the term ‘random.’”

Handcrafted copper details completed the distinctive, traditional look. Flat-seam copper panels from Revere Copper were installed in the valleys, using clips to allow for expansion and contraction. Copper counterflashing and step flashing were also custom fabricated. “We bend it to fit whatever we might need,” notes Dennison. “We have a talented sheet metal shop at our office where we fabricate the big stuff, but we also cut and shape panels on site.”

Photos: Charles F. Evans Company Inc.

Photos: Charles F. Evans Company Inc.

A detailed safety plan was set up for the building, which was open and active during the entire installation process. Scaffolds with decking were erected at the eaves, and temporary tunnels were engineered to protect pedestrians at the entryways.

The rake edges did not have scaffolding, so a safety perimeter was set up 6 feet from the roof edge. Workers outside the line had use a personal fall arrest system, which was secured to anchors screwed into the rafters. “All of our mechanics are extensively trained, and each year everyone goes through additional training sessions,” Dennison says. “We all know what we’re supposed to do. We have a very stringent plan on project safety.”

Slate itself can pose its own set of safety concerns. “Slate can be heavy and sharp,” Dennison says. “It’s rock. You have to be very careful, but the guys that do it love it. A lot of roofs these days are totally hidden. On a slate project, at the end of the day you can step back, see what you’ve done, and be proud your work.”

Charles F. Evans is just putting the finishing touches on the roof at Jones Hall. “When we’re done with a project and the customer is happy, that’s the best satisfaction you can get,” Dennison says. “When the client is happy and you look back and see a beautiful product that you know you had a hand in—that’s what I like about it. A slate roof is really a work of art that will stand the test of time.”

TEAM

Architect: eS Architecture and Development, Dublin, Ohio, esarchitecture.com
Roofing Contractor: Charles F. Evans Company Inc., Elmira, N.Y., Evans-roofing.com
Slate Supplier: Evergreen Slate Co. Inc., Grandville, N.Y., Evergreenslate.com
Copper Supplier: Revere Copper Products, Rome, N.Y., Reverecopper.com

Metal Roof Provides Durability, Energy Efficiency for Florida Preschool

The Goddard School in Ponte Vedra Beach was constructed from an existing building

The Goddard School in Ponte Vedra Beach was constructed from an existing building that was entirely gutted and remodeled. It features a standing seam metal roof manufactured by Metal Sales and installed by Ford Roofing Systems. Photos: Jacob Maust, Ford Roofing Systems Inc.

“Almost everything we do is kind of odd, weird and unique,” says Jay Maust, president and owner of Ford Roofing Systems Inc. in Ponte Vedra Beach, Fla. The company excels in high-end commercial and residential projects featuring metal, tile, slate and asphalt shingle roofing.

A recent metal roof installation in Ponte Vedra Beach was more straightforward than many of the company’s projects, notes Maust, but it has the aesthetics and architectural flair the company is known for. The project came to the company like all of the rest of the company’s jobs do: as a referral from an existing customer.

When the relative of a previous residential roof customer decided to completely gut, renovate and expand a building to put up a teaching preschool known as the Goddard School, Maust was called in to consult on the project, come up with a roof design and install it. The result was a standing seam metal roof that provides the durability and energy efficiency the school requires.

The existing shingle roof was torn down to the trusses, and any damaged trusses were replaced. After new wings were added, the building envelope was insulated with spray foam. New plywood decking was installed, and after the deck passed the county inspection, Maust dried the building in with Boral Tile Seal self-adhering underlayment. “It has great thermal properties to it,” he says. “In my opinion, it is the best peel and stick on the market.”

The next step was to install painted metal perimeter wall flashings for the metal roof system that would also serve as stops for the HardiePlank and stucco siding. “It not only provides waterproofing protection but creates a tie-in for our system,” says Maust. “We call it a receiver flashing. It provides a nice, straight line where the siding or stucco ends. There is typically blue plastic that covers the metal, and after the siding is installed, you just peel the plastic sheeting off, and any paint or residue that might have gotten on the metal is peeled off with the plastic. And the end you have a beautiful piece of metal that enhances the look of the building—and it’s a water barrier.”

The standing seam roof was manufactured by Metal Sales Inc. On jobs such as this one, the project superintendent typically measures the roof by hand and prepares a cut list for the manufacturer. Metal Sales shipped the finished panels to the site, including 24-gauge galvalume panels painted in Kynar Silver Metallic, drip edge, hip and ridge panels, and headwall flashing.

Precise Execution

Since the front entryway was still under construction, roofing crews began at the back of the building and worked their way forward. One hurdle was formed by the addition of a back wing, which had a primary support beam that intruded on a designed valley. Since the support could not be moved, Maust decided to change the slope of valley to avoid the potential eyesore.

Photos: Jacob Maust, Ford Roofing Systems Inc.

Photos: Jacob Maust, Ford Roofing Systems Inc.

Architectural details included shed dormers over the doorways and windows, as well as gable dormers with false louvers.

Proper placement of penetrations on metal roofs is critical, notes Maust, and the company takes pains to ensure that penetrations are kept to a minimum and are properly designed and executed. Crews make sure plumbing stacks are in the center of a panel and don’t interfere with the ribs. When plumbers rough in the stacks, roofing crews make sure the last section of pipe can be rotated to ensure it is in the center of a panel before the final cuts are made. “We make them go through this extra step,” Maust says. “If they won’t do it or can’t do it, we’ll do it for them.”

Coordinating work with representatives of other trades on the project was difficult, but it is necessary part of the process, according to Maust. Ford Roofing workers made sure to be on hand to assist framers, as well as contractors installing siding, stucco, fascia and HVAC equipment. “That is our roof, and we don’t want anyone else walking on it, period,” Maust says. “We’ll install weather vanes, cupolas—whatever’s going up there.”

The standing seam metal roof was installed after the building envelope

The standing seam metal roof was installed after the building envelope was insulated with spray foam. The result is a durable roof system that helps ensure energy efficiency for the building. Photos: Jacob Maust, Ford Roofing Systems Inc.

The company built a curb for one of the HVAC fan units, and flashed in another that had a factory-installed curb to ensure they looked identical. “We went up there and sealed it in and flashed it,” Maust notes. “We made it look like it was part of the roof.”

For those forced to walk on the panels, rituals include knocking boots on the ladder and wiping the soles with a towel to ensure no sand or grit could possibly mar the finish. “We use foam tubes on our ladders so we don’t scratch the paint,” Maust explains. “It’s a learned process, and we’ve learned a lot of things over the years.”

Safety is always the top priority on every project. “On steep–slope jobs like this one, everyone wears harnesses and is tied off to their own bracket, which is properly attached to a truss,” Maust notes. “We are always checking on each other. Sometimes it’s hard to see if someone is tied off when they are on the top of the roof, so we developed this little motion where someone on the ground will make a hand gesture, and the person on the roof will pull up his safety line to demonstrate they are tied off.”

The installation on this project went like clockwork, according to Maust. “I’ve been doing this since I was 14,” he says. “The key is logistics. Is there stress sometimes? Absolutely. You just have to pace yourself.”

Photos: Jacob Maust, Ford Roofing Systems Inc.

Photos: Jacob Maust, Ford Roofing Systems Inc.

Maust is detail-driven, but he realizes it’s people who must execute the error-free, eye-catching projects that generate referrals. “Success comes from having guys in the field that care,” he says. “They understand very clearly that if they do a good job, this job is going to lead to another job. They get that. I also get that.”

The key is to not only build strong roofs but strong relationships. “I’m a very social person when it comes to my homeowners and my contractors,” Maust says. “If I’m working for a contractor, I want to meet the homeowner and help them select their tile. I want my reps, my builders, my homeowners to embrace a project together. I want everybody to know everybody. You develop these friendships and relationships, and that’s where great projects and great referrals come from.”

“That’s how I get my work,” Maust concluded. “All of my projects come to us through word of mouth. I’ve never placed an ad.”

TEAM

Architect: Dig Architecture, Jacksonville, Fla., Dig-architecture.com
General Contractor: Benchmark Commercial Group, Jacksonville Beach, Fla., Benchmarkcommercialgroup.com
Roofing Contractor: Ford Roofing Systems Inc., Ponte Vedra Beach, Fla., Fordroofingsystems.com
Metal Roof System Manufacturer: Metal Sales Inc., Metalsales.us.com
Underlayment Manufacturer: Boral Roofing, Boralamerica.com/roofing

North Carolina Middle School Generates More Energy Than It Uses

Sandy Grove Middle School in Hoke County, N.C.

Sandy Grove Middle School in Hoke County, N.C., was designed to be an energy-positive building. It generates 40 percent more energy than it consumes. Photo: Mathew Carbone Photography

When Robbie Ferris first presented the idea of a school building that generates more energy than it uses, people were skeptical. Now he can point to Sandy Grove Middle School in Hoke County, N.C., as proof that a high-performance school building can go well beyond net zero and generate 40 percent more energy than it consumes.

Ferris is the president of SfL+a Architects and manager at Firstfloor, a development company that specializes in public-private partnerships and design-build-operate agreements. “We designed the building, we own it and we lease it to the school district,” he says. “We monitor all of the systems remotely. One of the reasons we do that is because when you put really high-performance systems in buildings, you have to make sure they are operating at peak efficiency. It can take time to make sure everything is optimized.”

Three years after completion, Sandy Grove Middle School is outperforming its energy models, and the building continues to win accolades. It recently received Energy Star 100 Certification and has been recognized as the nation’s most energy positive school.

“Sandy Grove Middle School is a perfect example of a high-performance facility,” says Ferris. “With the public-private lease-back model, everyone wins. The students receive a quality school, it fits in to the school system budget, and it is energy efficient to help both total cost and our environment.”

The building’s systems were designed to be as energy-efficient as possible, and that includes the roof, which features an array of photovoltaic (PV) panels to generate electricity. “We wanted a roof that would last 30 years,” Ferris notes. “We’ve had a tremendous amount of success with TPOs, and metal roofs as well. This particular client wanted a metal roof look from the front, but they were very open to a membrane roof on other parts of the building. We made the decision to put the metal roof on the front of the building and a TPO on the wings at the back of the building.”

On this project, the warranties were important considerations, along with durability and energy efficiency. SfL+a specified a standing seam metal roof system manufactured by Dimensional Metals Inc. and a TPO system manufactured by GenFlex. “Obviously, if you’re putting a couple of million dollars’ worth of solar panels on your roof, you want to make sure you have a roof that is going to be problem free.”

A Smooth Installation

The installation was a challenging one, but everything went smoothly, notes Aaron Thomas, president and CEO of Metcon Inc. Headquartered in Pembroke, N.C., Metcon is a full-service general contractor that specializes in energy positive commercial buildings, so it was perfectly suited to serve as the construction manager on the project.

Photovoltaic panels were installed

Photovoltaic panels were installed on both the standing seam metal roof and the TPO system. The systems on the low-slope roof sections are fully ballasted, and both sections were installed without penetrating the roof system. Photo: SfL+a Architects

Thomas and Ryan Parker, senior project manager with Metcon, coordinated the work of subcontractors on the job, including the Youngsville, N.C. branch of Eastern Corp., which installed the TPO and metal roofs, and PowerSecure, the solar installer on the project, based in Wake Forest, N.C.

The roof systems covered 85,000 square feet, and Sharp PV panels were installed on both the metal roof and the TPO system. Solar panels were also installed on freestanding structures called “solar trees.” Each solar tree is 20 feet tall, 25 feet wide and weighs 3,200 pounds.

“The TPO roof system was upgraded to an 80-mil product due to solar panels being added to the roof,” Parker notes. “It was 100 percent ballasted on the low-slope sections, with slip sheets being used below the racking on the TPO roof.”

On the metal roof, clips manufactured by S-5! were used to affix the solar racking to the seams. “There are no penetrations for the frames, and penetrations for the electrical wiring went through vertical walls, not the roof,” Parker says. “There were no penetrations anywhere in the roof system, which made all of the warranties that much easier to keep intact.”

The biggest challenges on the project, according to Parker, were coordinating the different scopes of work and ensuring all of the manufacturers’ warranty considerations were met. “We had two different kinds of roofs, both coupled with solar panels,” Parker says. “Like any rooftop with photovoltaic products, there had to be special attention paid to the warranties of all parties involved. Both Genflex and DMI were closely involved in coordinating details to ensure that the owner achieved a great roof free of defects.”

The building’s systems were designed for energy efficiency

The building’s systems were designed for energy efficiency, and the roof features an array of photovoltaic panels to generate electricity. Photo: Mathew Carbone Photography

One key was developing a detailed schedule and keeping everyone on it. “We would meet once a week and huddle up on how it was progressing and what else needed to be done,” Parker recalls. “We found that by using a collaborative submittal sharing platform, all of the varying parts and pieces could be checked by all parties to ensure compatibility.”

There were multiple safety concerns associated with combining solar panels to the roofing system, so everyone had to be on the same page. “The roofing subcontractor and the solar subcontractor performed a joint safety plan that utilized common tie off points,” Parker notes. “The job had zero lost time.”

“Everyone coordinated their work and it was a great team effort,” Ferris says. “It was one of the smoothest jobs I’ve ever seen. We have not had a single leak on that project—not a single problem.”

Proof Positive

For Ferris, the greatest obstacle on energy-positive projects convincing members of the public and governmental agencies of the benefits. “The biggest challenges had nothing to do with construction; they had to do with just doing something new and different,” he says. “The toughest challenge was getting the school board, the county commissioners, the public and the review agencies on board. It took a very long time—and lots of meetings.”

Photo: SfL+a Architects

Now Ferris can point to Sandy Grove as an example of just how a high-performance school building can pay huge dividends. “As soon as you see it in real life, you’re on board,” he says. “It’s very exciting for people to see it. If we can get people to the school, they’ll walk away convinced it is the right thing to do.”

With Sandy Grove, the school district has a 30-year lease with an option to purchase. Ferris believes the lease model is the perfect solution for educators. “We’re responsible for any problems for the life of the lease,” he says. “If a problem does come up, we usually know about it before the school does because we monitor the systems remotely online.”

“In their world, buildings are a distraction from educating kids,” Ferris concludes. “This is one building that is not a distraction.”

TEAM

Building Owner: Firstfloor, Inc., Winston-Salem, N.C., Firstfloor.biz
Architect: SfL+a Architects, Raleigh, N.C., Sfla.biz
Construction Manager: Metcon Inc., Pembroke, N.C., Metconus.com
Roofing Contractor: Eastern Corp., Youngsville, N.C.
Photovoltaic Panel Installer: PowerSecure, Wake Forest, N.C., Powersecure.com
Metal Roof System Manufacturer: Dimensional Metals Inc., DMImetals.com
TPO Roof System Manufacturer: GenFlex Roofing Systems, GenFlex.com

Copper Is the Solution for Challenging Residential Roof Restoration

This home in Alexandria, Va., was retrofitted with a copper double-lock standing seam roof system

This home in Alexandria, Va., was retrofitted with a copper double-lock standing seam roof system installed by Wagner Roofing. The 16-ounce copper roof panels were 17 inches wide. Photos: Landmarks Photography—Jay Stearns

“We like the tough jobs,” says Dean Jagusch, president and owner of Wagner Roofing Company. “We like the intricate jobs.”

Headquartered in Hyattsville, Md., Wagner Roofing has served the Washington area market for more than a century. “We specialize in historic restoration and innovative architectural roofing and sheet metal,” Jagusch notes. “We’re full service. We do slate, copper, tile, and have a low-slope commercial division as well. But our trophy stuff tends to be of the steep-slope variety.”

A recent residential restoration project in Alexandria, Va., certainly qualifies as “trophy stuff,” taking home a North American Copper in Architecture Award from the Copper Development Association (CDA) in the “Restoration: Roof and Wall” category.

It’s easy to see why. The origami-inspired design features multiple roof angles, but the daring design was problematic. Even though the home was relatively new, the owners were plagued by leaks. Along with Restoration Engineering Inc. of Fairfax, Va., Wagner Roofing was called in to consult on the project, determine the source of the leaks, and come up with a solution.

The original galvalume standing seam roof channeled the water into a large, stainless steel internal gutter with roof drains. Jagusch found that the leaks were occurring at two types of critical points. First, there were leaks where the internal roof drains met the central gutter. The other problem spots were along the pitch transitions.

Jagusch felt that installing a conventional-style painted galvalume roofing system in those spots was almost impossible. “We felt that was since it was an area that was failing, we wanted a metal we could work with when we met a transition and turn the panels vertical where we needed to without having to break them and rely on rivets and caulk,” he says.

Custom five-sided downspouts were fabricated

Custom five-sided downspouts were fabricated, but large windows at the back of the home offered few options for support. The downspouts were attached up under the framing system. Photos: Landmarks Photography—Jay Stearns

Copper was the answer. “The detailing was pretty tough to do, so we recommended changing it to copper so we could work with it, be able to solder and have a more seamless roofing assembly,” Jagusch recalls.

Another key to the project was redesigning how the roof drained. “We decided to push all the water to the exterior,” he says. “We collaborated with Restoration Engineering and we fleshed out the original redesign.”

The team decided that installing a copper roof system with a new drainage plan would be the best way to eliminate the leaks and keep the inspiring look the homeowners desired.

“We wanted to eliminate the drains and push all the water to the exterior, so that’s why we went for the re-slope of the big central gutter,” Jagusch says. “Also, at the transitions, we wanted to make sure we were 100 percent watertight, so we used a combination of turning up panels and soldered cleats to get everything into place.”

Solving the Puzzle

With its intersecting planes, the roof made laying out the panels an intricate puzzle. “You also had large expanses of roofing that changed pitch throughout,” Jagusch explains. “Panels had to be laid correctly because not only does the roof slope up, but it also slopes sideways. The layout of the panels was critical from the get-go. We all looked at it and agreed that we would follow parallel to the actual trusses, which we felt was the best solution.”

The old roof system was removed and stripped down to the 3/4–inch plywood deck. “We covered the entire roof deck with Grace Ultra,” said Jagusch. “We then used a slip sheet and installed 1-inch-high, double lock, 17-inch-wide, 16-ounce copper standing seam panels.”

Photos: Landmarks Photography—Jay Stearns

Photos: Landmarks Photography—Jay Stearns

Panels were roll formed at the Wagner metal shop out of 20-inch-wide coils using an ESE roll former and trailered to the jobsite. Approximately 5,400 square feet of copper panels were installed on the project. The double-lock seams were mechanically seamed. Twenty-ounce copper flat-seamed panels were used in the large valleys.

The safety plan included full scaffolding during every phase of the project. “We have our own safety scaffolding system,” Jagusch says. “Our guys demand it on our jobs, and we demand it of them to come home safely every day. We are very proud of our safety record. It’s front of mind for us.”

In addition to the roof, all of the metal cladding was replaced on the southeast feature wall. The top of the wall was reconfigured to accommodate the new sloped valley. Where the wall met the roof, a band was fabricated to match the top part of the fascia. Other details included copper cladding for the chimney.

Drainage was redirected to the perimeter, where custom-fabricated gutters were installed. “On the west side, the roof was originally designed to dump off straight onto a rock feature on the ground, but we fashioned a custom copper box gutter about 35 or 40 feet long,” Jagusch states.

At the either end of the large internal gutter and at the end of a large valley, shop-fabricated copper conductor heads were installed. Custom five-sided downspouts were fabricated, but installing them posed another challenge, as large window areas offered few options for support. The downspouts had to be snugged up under the framing system.

“Everything had to work with the other building components,” Jagusch explains. “One of the tougher things on this project was being able to have the function and the form both top of mind, in that order. The key was to make the functional stuff look good.”

Showpiece Project

The project was completed about a year ago, and the copper has begun to change in color. “The copper now has a gorgeous bronze, kind of purplish hue to it,” notes Jagusch. “I think it will eventually develop a green patina, but with the way the environment is these days, I think it will take 15 years or so before it gets to that point. That’s the cool thing about copper—it’s a natural, breathing material that is constantly changing, constantly evolving.”

Copper cladding was installed on a feature wall

Copper cladding was installed on a feature wall, which also featured changes in slope. The top of the wall was reconfigured and a band was added to match the top part of the fascia. Photos: Landmarks Photography—Jay Stearns

Wagner Roofing has a maintenance agreement in place on the home, so Jagusch has stayed in touch with the owners and kept tabs on the project, which is performing well. “I’ve got just one hell of a team here,” he says. “It wasn’t just one estimator that went out and brought this thing in. In our business, estimating and roofing is a team sport. We kicked this thing around a lot with all divisions of the company, from estimating to operations to the actual installers before we finally settled on a number for this thing.”

“We work on some pretty spectacular places, and of course this is one of them,” he concludes. “We like a challenge, and this is the stuff that my team really loves to get their teeth into.”

New Construction Project Tests Contractor’s Mettle

Photos: Lynn Cromer Photography, Ferris, Texas

Photos: Lynn Cromer Photography, Ferris, Texas

Independence High School in Frisco, Texas, was conceived as an impressive new construction project on a tight schedule. The standing seam metal roof of the building was a key component in the architectural planning, as it was designed to provide aesthetic appeal for the massive structure while minimizing the view of mechanical equipment for passers-by on the ground.

The roof also was comprised of several low-slope sections, which were covered with a modified bitumen system. Both the metal and modified systems contributed to the building’s energy efficiency, helping the project achieve LEED Silver status.

The roof systems were installed by the Duncanville, Texas, branch of Progressive Roofing Services. Randy Dickhaut, the company’s general manager, indicated the project was completed in approximately one year—an ambitious schedule for a job of this size. “It was a challenging new construction job,” he says. “There were a lot of logistics involved, but in general, the job went very well.

A Tale of Two Roofs

The first goal of the project was drying in the metal decking. A two-ply, hot–mopped modified bitumen system manufactured by Johns Manville was installed on 24 decks totaling approximately 195,000 square feet of low-slope roof area. The system was applied over two layers of 2 1/2-inch polyiso insulation and 1/2-inch JM Securock cover board. The system was topped with an Energy-Star rated cap sheet, DynaGlas FR CR.

Photos: Lynn Cromer Photography, Ferris, Texas

Photos: Lynn Cromer Photography, Ferris, Texas

In the nine sections where the 88,000 square feet of metal roofing was installed, two layers of 2 1/2-inch polyiso insulation were attached, along with plywood decking and self-adhering TAMKO TW Tile and Metal underlayment. The standing seam metal roof system was manufactured by McElroy Metal, and the company provided the manpower and equipment to roll form the panels on the job site. Roof panels were the company’s 22-gauge Maxima 216 panels in Weathered Galvalume. These panels were complemented by 24-gauge Flush panels on walls and soffits.

The roll former was mounted on a scissor-lift truck. The eaves of the building were approximately 36 feet off of the ground, so a sacrificial panel was used to create a bridging effect to help guide panels to the roof. “Basically, the roll former went right along with us,” Dickhaut recalls. “We would pull 30 or 40 squares of panels, then drop the machine and move to the next spot. We were able to roll the panels right off the machine and lay them in almost the exact spot they would be installed.”

Photos: Lynn Cromer Photography, Ferris, Texas

The length of some of the panels posed a challenge, and as many as 12 crew members were needed to guide them into place for installation. In the steep-slope sections, crew members had to be tied off 100 percent of the time, so retractable lanyards were used to help keep safety lines out of the way.

The roof was mechanically seamed using a self-propelled industrial roof seamer manufactured by D.I. Roof Seamers. “We call it walking the dog,” notes Dickhaut. “One man can operate the equipment, and he just walks it every inch of every seam.”

The metal roof was designed to hide the mechanical equipment for the building, and Progressive Roofing completed work on two deep mechanical wells before the HVAC equipment was installed. “In the wells, we used McElroy’s Flush panels for the vertical surfaces and transitioned to the metal roofing,” notes Dickhaut. “In the bottom of the mechanical wells, we installed the Johns Manville modified roof and flashed the curbs.”

Rising to the Challenge

Dickhaut points to a few challenges on the job, including the length of the panels and the weather. “Overall, the job went really well,” he says. “The architects did a great job on the design, and McElroy has really good details. It was a pretty straightforward process. There was a lot of wind and rain we had to cope with. When you have a 100-foot panel that you can’t kink or scratch, it can get kind of tricky. You just have to be very careful.”

Photos: Lynn Cromer Photography, Ferris, Texas

Photos: Lynn Cromer Photography, Ferris, Texas

The Texas weather made the schedule unpredictable. “We were on that job over a year, so we caught all four seasons,” he says. “Weather had a huge impact. We dealt with extreme heat, humidity, snow, ice, mud, monsoon-type rains. Texas throws anything and everything at you.”

Whatever the conditions, Progressive Roofing was ready. “We show up locked and loaded,” Dickhaut says. “We attack it. We have seasoned veteran roofers that lead the pack. On that particular project, we had an architect, roofing consultants, an owner’s rep, and a general contractor. We would also bring in the McElroy and JM reps periodically for consultation. It’s really a team effort.”

TEAM

Architect: Corgan Associates Inc., Dallas
General Contractor: Lee Lewis Construction Inc., Dallas
Roofing Contractor: Progressive Roofing Services Inc., Duncanville, Texas
