Acrylic Air Barrier Lowers Installed Costs

The acrylic air barrier resists air and water infiltration, saving energy and preventing moisture build-up.

The acrylic air barrier resists air and water infiltration, saving energy and preventing moisture build-up.

Kemper System America Inc. offers Wall Guardian FW-100A, a liquid-applied fibered acrylic air barrier that also acts as a water/weather barrier and vapor retarder. Evaluated by the Air Barrier Association of America (ABAA), it delivers air barrier performance – and value.

Wall Guardian FW-100A exceeds ASTM E2357 (Standard Test Method for Determining Air Leakage of Air Barrier Assemblies) with an air leakage rate of just 0.0004 cfm/ft2 @ 1.57 psf – 100 times better than the test requirement. Notably, the liquid-applied air barrier exceeded the standard in a single coat at 40 mils wet film thickness.

The engineered system is designed to resist air and water infiltration, saving energy and preventing moisture build-up that can lead to mildew and mold. Compared to house wraps and mechanically-fastened weather barriers, Wall Guardian FW-100A can be applied to building material surfaces with a sprayer, roller or brush.

The liquid-applied air barrier offers unified substrate protection, even on curved or other unconventionally shaped walls. The water-based coating is a low VOC product and meets LEED intent at 25 percent recycled content. The applied coating is also Class A fire rated.

In addition to Wall Guardian FW-100A, Kemper System also offers related air barrier component products through its STS Coatings line acquired in 2016. These include GreatSeal LT-100 polyether Liquid Tape for board-to-board joints, windows, doors, masonry, roof flashings, etc., and UT-40 Universal Tape for sealing cracks, transitions, penetrations and seams in exterior substrate and insulation board.

For over 60 years, Kemper System has been a leader in cold liquid-applied, reinforced roofing and waterproofing, having invented the technology. The company offers a full range of Building Envelope solutions to protect against weather, preserve the integrity of surfaces, and enhance the comfort and value of buildings. This encompasses Wall Guardian fibered acrylic air barrier, Roof Guardian Technologies elastomer-based roof coatings, and HeatBloc-ULTRATM radiant heat barrier. Other brands include COLEAN traffic coating systems, and the company flagship for exterior and interior waterproofing, Kemperol reinforced membrane systems.

To learn more, contact Kemper System at inquiry@kempersystem.net or call (800) 541-5455.

Self-Adhering Vapour Permeable Membrane Is Mold Resistant

The self-adhering vapour permeable membrane can be applied to common substrates such as gypsum, oriented strand board (OSB), block, concrete, concrete masonry unit (CMU) and plywood.

The self-adhering vapour permeable membrane can be applied to common substrates such as gypsum, oriented strand board (OSB), block, concrete, concrete masonry unit (CMU) and plywood.

IKO AquaBarrier VP Self-Adhering Vapour Permeable Membrane provides a primerless vapour permeable membrane solution with mold resistance for a variety of building envelope applications.

Self-Adhering, Versatile Applications
A self-adhering, primerless membrane, AquaBarrier VP, provides superior performance in wall assemblies where a vapour permeable, weather-resistive air barrier is required.

Thanks to the vapour permeable matrix of AquaBarrier VP, it is compatible and can be applied to common substrates such as gypsum, oriented strand board (OSB), block, concrete, concrete masonry unit (CMU) and plywood. The membrane is also designed for various applications, including masonry cavity walls, metal cladding systems, renovations and retrofits, siding, curtain walls and parapets.

The design of the AquaBarrier VP membrane allows for installation ease, with no mechanical attachments or primer required for standard application. Coated with a proprietary acrylic adhesive on the back surface, AquaBarrier VP offers performance for common wall applications and features a polypropylene release film to aid in removing the membrane.

AquaBarrier VP is an effective vapour permeable membrane when installed according to IKO specifications.

AquaBarrier VP is constructed of a polyolefin synthetic polymer (fibre) membrane with low water retention capacity and is therefore mold and mildew resistant.

The IKO AquaBarrier line includes a full range of membrane and accessory products that provide protection in wall assemblies with air and vapour barrier systems. Engineered to meet or exceed industry standards, the line includes self-adhering and torch-on wall membranes, through-wall flashing membrane, foundation protection and flashing tapes.

For more information on AquaBarrier VP and details on IKO’s commercial wall and roofing system solutions and accessories, visit the IKO website.

Conversion Kit for PaceCart Is an Economical Option

The Pace Cart Conversion Kit can help contractors dispense more OlyBond 500 Adhesive per hour.

The Pace Cart Conversion Kit can help contractors dispense more OlyBond 500 Adhesive per hour.

OMG Roofing Products has introduced a Conversion Kit for the PaceCart that enables contractors to use 15 gallon drums (30 gallon sets) of OlyBond500, rather than 10 gallon Bag-in-Box sets. The Pace Cart Conversion kit (patent pending) is designed for use on PaceCart 2B and PaceCart 3 equipment, and provides contractors with an economical option compared to purchasing new equipment or other retro kits on the market. Once installed, the Conversion Kit can help contractors dispense more OlyBond 500 Adhesive per hour.

Some Assembly Required

Assembly of the 15 Gallon Drum Conversion Kit onto a PaceCart can be completed by one person in about 10-15 minutes. Tools required for the assembly include an Allen-wrench (provided), screw gun with 5/16-in. bit (5/16-in. bit provided), and screwdriver. Assembly on a PaceCart 3 also requires an adjustable wrench.

After installation, contractors have a choice of applying OlyBond Adhesives from either the Bag-in-Box sets or from 15 gallon drums. OMG 15 Gallon Drum Conversion Kits are in-stock and available. In addition, written and video installation instructions are available and on-line here.

Chem Link Expands Penetration Seal System Line

Chem Link now offers a 5-inch E-Curb penetration seal system, the newest size offering in the full E-Curb line of products. Designed to better fit contractor needs, lighter-weight E-Curbs feature interlocking “slip-fit technology,” which is designed to allow for quick assembly and easy installation.

E-Curbs are designed for use on granulated modified bitumen, asphalt and coal tar built-up roofing applications, as well as PVC, PIB and TPO single-ply roofing membranes. All E-Curb kits come with gloves, 1-Part Pourable Sealant and M-1 Adhesive/Sealant to complete the job.

Acoording to the manufacturer, all E-Curbs offer excellent adhesion to most roofing materials.
No flashing or mechanical attachment is required. Service temperatures range from -40°F to 200°F (-40°C to 93°C).

“We’ve seen significant growth in the solar industry for a need for a 5-inch E-Curb,” said Jeff Piotrowicz, product manager, Chem Link. “Additionally, this new size allows greater flexibility for our contractors to create a durable, waterproof rubber seal around penetrations and extends our current E-Curb offering for steep slope roofs.”

Chem Link E-Curb

Silicone Sealant Repairs Roofs, Masonry and Sheet Metal

The 100 percent Silicone Sealant seals and repairs roofs, masonry, architectural sheet metal, and metal roof seams and fasteners.

The 100 percent Silicone Sealant seals and repairs roofs, masonry, architectural sheet metal, and metal roof seams and fasteners.

Mule-Hide Products Co. has added 100 percent Silicone Sealant choices to its Silicone Roof Coating System, expanding the color offering to include clear and the packaging options to include 10-ounce tubes.

100 percent Silicone Sealant is a mastic version of the Mule-Hide 100 percent Silicone Roof Coating. It is a moisture-cure silicone sealant designed for use in sealing and repairing roofs, masonry, architectural sheet metal, and metal roof seams and fasteners.

The addition of clear sealant allows contractors to complete projects that would otherwise require color-matching. It is available packaged in tubes only.

In addition to clear, the tubes are available filled with white sealant. The plastic cartridges are an option for use in smaller applications or when precision is required. They also can be submerged under water to repair roof leaks, gutters and downspouts.

100 percent Silicone Sealant provides adhesion to concrete, masonry, polyurethane foam, EPDM membranes, TPO membranes, aged PVC membranes, aged acrylic coatings, granular cap sheets, wood, metals, Kynar finishes and most other building materials. When using 100 percent Silicone Sealant with a TPO roof membrane, Mule-Hide Si TPO Primer must be applied first.

The sealant has minimal odor, making it contractor- and building-occupant-friendly. Its volatile organic compound (VOC) content of less than 10 grams per liter makes it acceptable for use in areas with VOC restrictions. It does not corrode metals.


New Two-Part Polyurethane Adhesive Cures in Minutes

DUOTACK 365Manufactured by Soprema, DUOTACK 365 is a new low-rise, two-part polyurethane adhesive for adhering insulation boards, cover boards or thermal barriers. It is a higher-performing formulation of the company’s standard DUOTAK and will be universally accepted for use anywhere that the standard formulation was used. According to the manufacturer, DUOTACK 365 meets FM, UL and FBC regulations. The new product can be stored more easily and cures in minutes. The adhesive contains no VOCs and comes in two-part cartridges, 10-gallon container sets, and 50-gallon drums.

Multi-Purpose Structural Adhesive and Sealant Designed for Wide Range of Uses

M-1 Structural AdhesiveChem Link, formulator and manufacturer of high-performance adhesives, sealants, coatings and related products for application throughout the building envelope, introduces the benefits of the M-1 multi-purpose structural adhesive and sealant. M-1 is designed for bonding and sealing a wide range of construction materials.

M-1 offers 400 psi shear strength, 575 percent elongation, and a Class A fire rating. M-1 is most often used for flashing, coping, skylights and HVAC applications, as well as an emergency repair sealant for temporary repair of leaks.

“We work closely with our customers to develop products that combine high performance with safety,” said Jeff Piotrowicz, product manager, Chem Link. “We’re proud to offer M-1, which provides versatility for the industry with its ability to form a tough, waterproof seal on most roofing materials.”

Ensure Blister-free Installation of EPDM Bonding Adhesive

EPDM x-23 Low-VOC Bonding Adhesive boosts roofing crew productivity while helping ensure blister-free installations of EPDM roofing systems.

EPDM x-23 Low-VOC Bonding Adhesive boosts roofing crew productivity while helping ensure blister-free installations of EPDM roofing systems.

With its fast flash-off, easy application and extended open time, EPDM x-23 Low-VOC Bonding Adhesive from Mule-Hide Products Co. boosts roofing crew productivity while helping ensure blister-free installations of EPDM roofing systems. The adhesive quickly creates a strong bond between EPDM membranes and a variety of porous and non-porous substrates. It is easily applied using a 9-inch medium nap roller. An extended open time—the period after flash-off during which the adhesive film remains tacky—makes EPDM x-23 Low-VOC Bonding Adhesive a good choice when working with larger EPDM sheets. It also allows sheets to be left open longer, enabling more solvent to escape and further reducing the potential for blistering.

Pipe Flashing Seals in Extreme Environments

316L Stainless Steel Ultimate Pipe Flashing combats the effects of salt water, chloride, extreme sunlight exposure and pipe thermal movement.

316L Stainless Steel Ultimate Pipe Flashing combats the effects of salt water, chloride, extreme sunlight exposure and pipe thermal movement.

Lifetime Tool & Building Products has released its 316L Stainless Steel Ultimate Pipe Flashing, which combats the effects of salt water, chloride, extreme sunlight exposure and pipe thermal movement, the major causes of plumbing pipe flashing failures resulting in roof leaks. Made of true marine-grade stainless steel, the product provides a precision seal to the pipe with a flexible bushing made from an ultra-pure silicone elastomer, which accommodates daily movement from thermal changes on the roof. The pipe seal is reinforced with a solid PVC collar engineered to provide lifelong compression of the seal to the pipe.

Joint and Termination Sealant Designed for Large Joints, Roof Termination Bars

JTS 1 joint and termination sealant from Mule-Hide Products Co. The new JTS 1 joint and termination sealant from Mule-Hide Products Co.allows contractors to quickly and easily seal large joints and roof termination bars – including those submerged under water – with no sagging or shrinking and minimal odor. According to the manufacturer, the 100-percent solids, moisture-cure urethane sealant delivers excellent adhesion to EPDM and PVC membranes, concrete, masonry, wood, vinyl and other common building materials. Primer is required when using it on TPO membranes.

The joint and termination sealant is designed to offer exceptional workability for quick, easy application in both dry and wet surface applications. It has a tack-free time of just 30 minutes. The solids content of JTS 1 eliminates shrinking and sagging. The sealant can, therefore, be used to provide watertight closure of joints up to 2 inches wide and 1 inch deep.

JTS 1 is isocyanate-free, enabling it to be packaged in durable plastic cartridges without losing workability. Unlike cardboard tubes, the cartridges can be submerged under water to repair roof leaks, gutters and downspouts. They also better withstand the rigors of transportation, storage and jobsite conditions without becoming damaged.

Solvent-free JTS 1 has minimal odor. Its volatile organic compound (VOC) content of less than 10 grams per liter makes its use allowable in areas with VOC restrictions. It is available in eight colors – white, black, bronze, gray, limestone, wicker/tan and terra cotta.
