Metal Panels Create High-Tech Appearance for Energy-Positive School

Myrtle Beach Middle School is engineered to be net-energy positive, and the building’s façade was developed to reflect its high-tech performance goals. Photos: hortonphotoinc.com

The new Myrtle Beach Middle School in Myrtle Beach, South Carolina, offers a vision of the future, in both its eye-catching design and award-winning performance. The school, like four other new elementary and middle schools opened in less than two years by the Horry County School District (HCSD), is engineered to be net-energy positive. This means the schools were designed to generate more energy than they use over the course of the year.

Designers mirrored that top-tier energy performance in their plans for a dynamic façade, punctuated by sharp corner angles, punched-out window shading and a dramatic entrance canopy. A bold color scheme created by broad expanses of PAC-CLAD Precision Series metal panels emphasizes this strong architectural statement.

“We felt we were creating a state-of-the-art facility. We wanted to create cutting-edge architecture to emphasize the cutting-edge approach of the school,” says Derrick Mozingo, AIA, senior partner and design principal with the hometown firm of Mozingo + Wallace, which designed the floor plans and exteriors of all five new schools in the HCSD system. “You don’t go by these buildings without noticing them.”

Designers developed a dynamic façade using PAC-CLAD Precision Series metal panels. The design features sharp corner angles and a dramatic entrance canopy.

Mozingo’s firm was a key member of the design/build team that brought HCSD’s five new schools — including two other middle schools, an elementary and intermediate school — online in only 18 months. FirstFloor Energy Positive led the effort, with SFL+A as design professionals of record and Stantec doing interior design and programing work. Panel and roofing installer Spann Roofing also was on board from the start. That company’s president, Jimbo Spann, says the fast-track schedule kept his installers on their toes.

“It was a big undertaking. There was a lot of design going on throughout the project,” he says. “There were time periods when we were working on several schools at the same time.”

In total, Spann’s team installed more than 100,000 square feet of PAC-CLAD 0.40-gauge aluminum HWP panels across all five schools, with colors chosen to highlight each facility’s athletic team’s colors. According to Mozingo, Petersen’s PAC-CLAD product supported both his budget and his aesthetic vision for the schools.

“It created a very affordable skin, and there was no other material out there that would create that look,” he says. “It gave us a surface that would weather well and gave us that architectural ‘tech’ look we were trying to achieve. We went through a number of studies to get what we ended up with.”

Mozingo notes he and his team also counted on Spann Roofing’s expertise as they went through their studies. “We have had a relationship with Spann Roofing for 30 years,” he says. “They worked with us through the design process and were a large component of that process.”

For Spann’s installers, familiarity with the product and with Petersen also were big advantages. With its responsibility for the wall panels as well as roofing for all five schools, Spann Roofing depended on the kind of responsiveness to questions and schedule demands they knew Petersen could provide.

“Petersen was very helpful, making site visits and making sure everything was going well and that we didn’t have any questions,” he notes, adding that the company also was critical in helping Spann keep up with HCSD’s aggressive timeline. “That took a lot from Petersen as well, in having the material ready on time. Without the material, we could have been in a world of trouble.”

With all five schools open, Spann now has had a little time to reflect on yet another successful project with Petersen and the company’s PAC-CLAD panels. “We know Petersen very well,” he says. “They’re like us – they do high-quality work and take a lot of pride in what they do, and it’s a top-of-the-line product.”

TEAM

Architect: Mozingo + Wallace, Myrtle Beach, South Carolina, www.mozingowallace.com

Wall Panel Installer: Spann Roofing, Conway, South Carolina, www.spannroofing.com

MATERIALS

Metal Wall Panels: PAC-CLAD 0.40-gauge aluminum HWP, Petersen, www.pac-clad.com

A New Roof Now Protects Priceless Literature at the Yiddish Book Center

The Yiddish Book Center was designed to resemble a shtetl, or traditional Jewish town. The complex features multiple steep-slope roof sections with distinctive double rooflines. Photos: Joshua Narkawicz

The Yiddish Book Center is a nonprofit organization whose mission is to preserve and celebrate Yiddish and modern Jewish literature and culture. Located in Amherst, Massachusetts, the Center is a repository for historic works of literature and art, and it hosts various educational and cultural programs throughout the year to share them with others. The complex that houses the Yiddish Book Center was designed to resemble a shtetl, or traditional Jewish town common in Eastern Europe before World War II. The effect is achieved by incorporating multiple steep-slope roof sections with distinctive double rooflines, all topped by cedar shakes. But when the natural cedar shake roof system began to fail, the priceless works of art and literature were suddenly at risk.

Administrators reached out to Tech Roofing Service Inc., Chicopee, Massachusetts, to repair the leaks and assess the condition of the roof, which included several interlocking steep-slope and low-slope sections. Tech Roofing, founded in 1975, focuses primarily on commercial projects and prides itself on its ability to install a wide variety of systems.

Joshua Narkawicz, vice president of Tech Roofing, says the company thrives on jobs with multiple scopes of work. “We like complex jobs,” he says. “Those are the ones we love. We’re not afraid of anything — the more difficult, the better.”

As Tech Roofing repaired the leaks, Narkawicz realized the roof was nearing the end of its service life. Tech Roofing crew members handled preventive maintenance issues while they worked with the Yiddish Book Center to develop a plan and a budget to replace the entire roof system.

Formulating the Plan

“Two years ago, we started to develop a game plan of what the end stage was going to be on re-roofing,” Narkawicz says. Working with the client and the original architect, the team explored re-roofing with wood shakes, as well as various options for synthetic shake roofing. Narkawicz worked with his local supplier, Beacon Roofing Supply’s branch in Chicopee, Massachusetts, to obtain samples of various synthetic shake products. The goal was to find the product that would most closely mimic the look of real cedar shake while providing a longer service life with fewer maintenance issues. “They ended up deciding to go with the DaVinci Multi-Width Shake product in Tahoe.”

Tech Roofing replaced all of the steep-slope and low-slope roofing on the project, installing custom-fabricated copper flashing and drip edge.

The schedule would be a daunting one, as the job would have to be sandwiched in during a summer break period, with work beginning right after a major event in mid-July and wrapping up before the end of August. “They still had some classes being conducted over the summer, so were kind of playing hopscotch,” Narkawicz notes. “There were four buildings we had to kind of jump around to work on.”

The removal of the existing steep-slope roof was the first step. “We ended up tearing off the existing wood shakes and breather vent,” Narkawicz says. “There was 30-pound felt beneath every layer. We tore everything off, down to the existing tongue-and-groove, which was in beautiful shape.”

As one crew did the tear-off work, a second crew installed custom fabricated copper drip edge and applied Grace Ice & Water Shield to dry in each section before the end of the day. The roofing crew then started installing the synthetic shake roofing tiles.

“Guys were falling back and setting the DaVinci starter courses over the custom fabricated copper drip edges,” Narkawicz explains. “We then started snapping lines and installing the DaVinci Multi-Width Shake. They chose a 9-inch exposure, and it has a multi-width pattern, so they range from 4 inches to 6 inches to 8 inches, and are staggered to get the desired look.”

The synthetic shake tiles were installed using a nail gun and 1-5/8-inch coiled ring shank nails. “There are marks on each shake that determine precisely where the nails should go,” says Narkawicz.

Administrators wanted to find a synthetic shake product that would closely mimic the look of natural cedar shake while providing a longer service life. They chose DaVinci Multi-Width Shake in Tahoe.

With the hut-shaped roofs bunched closely together, the courses had to line up perfectly, so crews were meticulous in the installation process, checking it carefully against the other sections as work proceeded.

At the horizontal break at the mid-roof, it was like starting the roof installation all over again. “That break was purely an aesthetic feature,” says Narkawicz. “We got the shingles up underneath there as high as we could. There was an existing head flashing there, and we sealed it in with copper ring shank nails as the counterflashing went over it. Then we started on the next tier, installing another copper drip edge and starter course, just like we were starting a separate roof.”

Some of the steep-slope roofs had a small section of flat roofing at the peak, while others had ridges where GAF Cobra ridge vent was installed. “DaVinci has pre-molded ridge caps, and we used those on the hips and on the ridge for a uniform look,” says Narkawicz. “They were actually really easy to install.”

After the steep-slope work was completed, work began on the low-slope sections. Tapered insulation was installed and topped with a 60-mil fully adhered EPDM roof system from Carlisle. Tech Roofing crews also rebuilt a small cupola, which was sided with rough cedar planks.

Overcoming Challenges

Challenges on the project included not only the compressed schedule but tricky logistics at the jobsite. Crews had to work closely with the Yiddish Book Center to make sure work did not affect ongoing classes. Narkawicz credits Ollie Schmith, the building and grounds supervisor, for helping coordinate the schedule. “He was phenomenal,” Narkawicz says.

The property is bordered by an apple orchard and has streams running through it, so access to some roof areas was difficult. There are also several elevation changes, and the back of the building features a landscaped terrace.

“We had to make sure the roof was set up correctly with the crane,” Narkawicz states. “We also had two scissor lifts on site, as well as a shingle buggy — the Equipter. The Equipter was huge for the tear-off because of the distances we had to travel to the dumpsters, which had to be located at the edge of the site.”

The project featured a multi-pronged safety plan. On the flat roof, crews used stanchions with a warning line and a safety monitor. During the steep-slope installation, crew members did some of the work from lifts, while other areas were scaffolded. Workers on the sloped sections were tied off at all times. “The guys would have ropes and harnesses,” explains Narkawicz. “We used planks and brackets for the removal, and we would have the shingle buggy down at the bottom to catch the debris. When we started going back up, we had the scissor lifts at the bottom with the material, and the guys did the first 5 feet or so working from the scissor lifts.”

Rainy weather made the schedule even tougher, and crews worked on weekends to keep the project on track. Narkawicz credits the teamwork of his company’s multi-talented crews for the successful outcome of the project.

“It was a great project overall, and a great client to work for,” Narkawicz says. “It just demonstrates the expertise of all the guys. We did the carpentry work, the sheet metal, the installs, the ripping. That’s a huge part of our company — we all do everything as one.”

TEAM

Roofing Contractor: Tech Roofing Service Inc., Chicopee, Massachusetts, https://techroofing.com

MATERIALS

Synthetic Shake: DaVinci Multi-Width Shake in Tahoe, DaVinci Roofscapes, https://www.davinciroofscapes.com

Underlayment: Grace Ice & Water Shield, GCP Applied Technologies, https://gcpat.com/en

Ridge Vent: Cobra Ridge Vent, GAF, www.gaf.com

EPDM Roof System: 60-mil EPDM, CarlisleSynTec, www.carlislesyntec.com

Cornell University Restoration Project Puts Team to the Test

Photo: Cornell University

Originally built in 1868, Morrill Hall was the first newly constructed building on Cornell University’s campus in Ithaca, New York. It is one of three structures built using Ithaca bluestone that are collectively known as “Stone Row.”

Buildings don’t last forever. Some need to be renovated every 150 years or so, and Morrill Hall is no exception. This year Cornell University and Charles F. Evans Company, Inc. completed an ambitious and extensive structural renovation project designed to restore the building to its former glory.

The scope of work included replacing the entire roof system at Morrill Hall, including the slate on the mansards and the standing seam metal on the main roof — a total of 3,780 square feet in all. Additional work included rebuilding and waterproofing the built-in gutters, replacing all 27 fourth-floor windows, repairing the ornamental wood cornice, and repointing the stone chimneys.

Morrill Hall was originally built in 1868. It was constructed from Ithaca bluestone. Photo: Charles F. Evans Company, Inc.

The installation challenges were daunting, but so were the environmental concerns posed by the existing materials, which included asbestos and lead. It would take a talented team of design and construction professionals to make it happen. Companies formulating and executing the overall plan included architect Bell & Spina, the construction team at Cornell University, and Charles F. Evans Company, Inc., which served as both the construction manager and roof system installer on this project.

Members of parent company Evans Roofing Company Inc. and Charles F. Evans Company, Inc., who shared their insights on the project with Roofing magazine included Bob Pringle, vice president at Evans Roofing Company; Don Sewalt, construction manager at Charles F. Evans Company; and Dan Nowak, corporate risk manager at Evans Roofing Company. They cited the teamwork of everyone involved on the project as the key to overcoming its many challenges. “The success story for this project was the working partnership we developed with all of the stakeholders,” says Pringle.

Environmental Concerns

Before restoration work could begin, known hazardous materials had to be removed. “There were multiple environmental issues on this job, including asbestos, lead in the metal and lead in the piping of the window glazing,” notes Pringle. “We had to abate all of these areas prior to even tearing off the existing roof.”

Ventilators were custom fabricated in Charles F. Evans Company, Inc.’s sheet metal shop. Crews also installed permanent anchor points pre-engineered by Thaler Industries. Photo: Charles F. Evans Company, Inc.

The company is licensed and all personnel certified in both asbestos and lead abatement for the construction industry. “We are licensed and certified in New York State to remove roofing, which is a significant benefit for our client in reducing costs,” Pringle says. “New York State has very stringent standards, which Charles F. Evans Company, Inc. goes above and beyond for their abatement practices.”

Care had to be taken to ensure no faculty members, students or pedestrians inside or outside the building would be exposed to contaminants or debris. Proper barricades and signage were used to keep everyone away from the abatement areas during the removal process.

Due to the lead time required for the abatement process and the windows, work began at the mansards. W.L. Kline was called in as a subcontractor to rebuild the cornice, remove and install the windows, and handle finished carpentry on the window frames.

The radiused roofs over the dormer windows were field fabricated. Photo: Charles F. Evans Company, Inc.

As the slate was being removed, roofing crews began the process of removing and rebuilding the gutters. The existing gutter system had to be removed according to the abatement standards, as it was constructed of lead-coated copper and lined with a built-up system containing asbestos in the felt. After the original structural sills were replaced, the gutter was rebuilt and topped with Kemperol 2K PUR, a membrane-reinforced, liquid-applied waterproofing system manufactured by Kemper System.

The next step was replacing the curved dormer roofs. “As we installed plywood on the mansard, we also removed the radiused roofs over the dormer windows,” says Sewalt. “We were field fabricating all of the sheet metal, which was a Freedom Gray flat seam. Everything was covered with ice and water shield. We used Polystick MTS, and then covered that with 30-pound felt from CertainTeed before all the radiused roofs were hand soldered in place.”

Installing the Roof Systems

As crews continued on the mansard sections, others began to tackle the main roof. On the mansard, crews installed North Country Unfading Black roofing slate supplied by New England Slate Company. The slate was custom cut to a hexagon shape to match the originals. The slates were all hand nailed in place. Some of the slate had to be hand cut to fit precisely around the curved dormer roofs. Making sure the courses lined up perfectly where they met up at the top of the dormers was critical. “It was meticulous work,” Sewalt says.

The building was fully scaffolded at the eaves. All scaffolded surfaces are fully planked and included a guardrail system and debris netting. Photo: Charles F. Evans Company, Inc.

Where the mansard roof meets the upper roof, attention to detail was crucial. “We shop fabricated our own cornice metal and counter-flashed the top course of slate,” says Sewalt. “We tied in to the eave of the Terne-coated stainless on the upper roof.”

Metal for the upper roof was purchased from Roofinox in coils, and the stainless-steel panels were fabricated in Charles F. Evans Company’s sheet metal shop. After the old roof was removed, new three-quarter-inch plywood was installed over the top of the existing random rough-cut deck boards. Crews then applied Polystick MTS self-adhered underlayment and rosin paper before installing the double-lock metal panels.

The original Ithaca bluestone chimneys were repointed by R.E. Kelley, the masonry restoration subcontractor, and new shop-fabricated step flashings were installed. Charles F. Evans Company also fabricated the large ventilators. “The louvered ventilators were very detailed,” Sewalt points out. “They were all custom fabricated in our sheet metal shop.”

One of the last phases of the roofing portion of the project was the installation of low-slope roofs on two lower-level areas that covered mechanical rooms. “We installed a two-ply modified bitumen system by Soprema,” Sewalt says. “We used Sopralene 180 sanded as a base, and Sopralene 180 FR GR White as the cap.”

The Safety Plan

The height, age and nature of the work posed numerous safety concerns, according to Pringle, but experience on other similar projects helped the company structure a detailed safety, health and environmental plan for Morrill Hall. “Charles F. Evans Company, Inc. is a VPP Mobile Workforce STAR contractor, the only union roofing company in the United States to have this prestigious status,” notes Pringle. “We had to make sure all of our employees were safe, as well as students, faculty, and the members of the public.”

The black roofing slate supplied by New England Slate Company was custom cut to a hexagon shape to match the original. Photo: Charles F. Evans Company, Inc.

A scaffolding system was central to the safety plan. “We had this one fully scaffolded,” notes Nowak. “We try to do this on all of projects if we can. We do it for safety, of course, but secondly it makes it a little bit easier for our crews. Going up a scaffolded stair tower sure beats a ladder any day for safety, and all scaffolded surfaces are fully planked with a guardrail system and debris netting. This way, it protects everyone occupying it and staging our materials and tools are allowed with the proper load ratings. It makes it so much easier to look at the work right in front of them and do the work in a safe manner.”

On the upper roof, workers were tied off 100 percent of the time. As part of the project, crews also installed permanent anchor points pre-engineered by Thaler Industries.

“Cornell has always been on the forefront with safety, not only for the public, the students and the faculty, but their maintenance crews as well,” Nowak says. “We are seeing a lot more permanent fall protection being installed on campus buildings, which is a great thing.”

The safety plan had to also protect people entering the building, as it was in use for much of the installation process. “We had to have proper barricades, signage, and of course entryway protection,” Nowak says. “We basically created a tunnel system with overhead protection so people could access the building.”

Landmark Renovation

Roofing work began in June 2018 and was completed in December 2018, so inclement weather was another big challenge, but the project was completed on time with zero safety incidents. According to Pringle, one key to meeting the deadline was the company’s ability to handle the abatement work itself, which optimized efficiency. “Everybody on that rooftop was certified for abatement, so we could tear and go and keep moving without calling in a subcontractor,” Pringle states. “It’s critical that we can do this work ourselves.”

Pringle and Sewalt commended everyone who worked on the project, including Jim Wilson, roofing superintendent; Brian Babcock, sheet metal superintendent; Brett Sewalt, slate foreman; and Brent Spencer, sheet metal foreman. The roofing crew included Brian Sewalt, Nate Uram, Cal Uram, and Bill Jordan. The sheet metal crew included Sam Morich, Neal Brown, Matt Denson, Bob Corwin, Tony Hoskins, and Jeff Worsfol.

To rebuild the historic landmark with the products of today, bring it up to code, and maintain the original look, is a tremendous accomplishment. “This was a collaborative effort between Charles F. Evans Company, Inc., Cornell University, and Bell & Spina,” Pringle says. “What we leave behind is our craftsmanship. Our client, Cornell University, once again depended on us to deliver another landmark renovation for them. Morrill Hall will continue to dominate ‘Stone Row,’ offering students and faculty a place to learn for years to come.”

TEAM

Owner/Representative: Cornell University (Patrick Conrad), Ithaca, New York, www.cornell.edu

Architect: Bell & Spina, Syracuse, New York, www.bellandspina.com

Construction Manager and Roofing Contractor: Charles F. Evans Company, Inc., Elmira, New York, www.evansroofingcompany.com

Window Contractor: W.L. Kline Inc., Binghamton, New York

Masonry Contractor: R.E. Kelley, Bowmansville, New York, www.rekelley.com

MATERIALS

Slate: North Country Unfading Black Roofing Slate, New England Slate Company, www.newenglandslate.com

Metal Roof Panels: Terne-Coated Stainless Steel, Roofinox, www.roofinox.com

Underlayment: Polystick MTS, Polyglass U.S.A., Inc., https://polyglass.us

Felt: Roofers’ Select 30-pound Felt, CertainTeed, www.certainteed.com

Flat-Seam Dormer Roofs: Revere Freedom Grey copper, Revere Copper, www.reverecopper.com

Modified Bitumen Roof: Sopralene 180 and Sopralene 180 FR GR, Soprema, www.soprema.com

Gutter Lining: Kemperol 2K PUR, Kemper System, www.kemper-system.com

Roof Re-Cover Meets Challenges of Historic Integrity

Austin Hall is a historic landmark on the campus of Sam Houston State University. It was first occupied in October 1851. Photos: McElroy Metal

Some roofers are simply cut out to do their thing in the spotlight. Empire Roofing of Austin, Texas, executed the removal of an existing leaking stainless-steel metal roof and the installation of McElroy Metal’s 238T symmetrical copper standing seam roofing system on a historic centerpiece building on the campus of Sam Houston State University.

Historic Austin Hall in Huntsville, Texas, was re-roofed less than 10 years ago. It’s the oldest building west of the Mississippi River to have been used continuously by an educational institution. Austin Hall was first occupied in October 1851 and completed the following year.

Unfortunately, it soon became evident that there were defects pertaining to the 2009-10 roof installation and it needed to be replaced. The stainless-steel interlocking panels were not seamed or soldered as specified and in accordance with historically accurate methods, resulting in widespread water infiltration beneath the metal roof assembly. Armko Industries of Austin was contracted to determine the best plan of action for resolving these issues and restoring the Austin Hall roof, internal gutters and cupola back to a watertight condition. During the evaluation, portions of the existing roof had to be removed to verify conditions. Sam Houston State and Armko requested Empire Roofing assist the evaluation.

At the base of the cupola, the specifications called for the installation of through-wall flashing using 20-ounce copper. Photos: McElroy Metal

“Based on my initial observations, I was hired to come in and actually remove and replace some of the roof near the cupola and internal gutters to assess and verify the exact nature of the perceived defects,” says Aaron Todd, who leads the metal roofing and sheet metal division at Empire Austin. “I hated to be the bearer of bad news, but it was a lot worse than they anticipated. The flat-seam panels were installed using a Pittsburgh seam, which really isn’t designed to be a watertight seam in a low-slope (2:12) roofing application. The underlayment that was installed did a better job of keeping out water than the flat-seamed panels.”

Working together, Empire and Armko put together a plan that required the removal of the stainless-steel flat-seamed panels and the internal gutter liner. The Texas Historical Commission was involved in the renovation to ensure the new roof would be as historically accurate as possible. Plans and specifications issued by Armko Industries were to remove the existing stainless steel and to re-roof with the 20-ounce copper 238T standing seam on all roof sections, interior gutters and related sheet metal components. Specifications and details issued siding removed at the cupola walls and a new liquid-applied waterproofing membrane was applied over the new sheathing, with new siding installed to match the original siding. At the base of the cupola, the specifications and details called for the installation of through-wall flashing using 20-ounce copper. Titanium PSU-30 high-temp self-adhering underlayment covered the roofing substrate and was used as a lining in the internal gutters, under the 20-ounce copper.

Empire Roofing removed the building’s existing roof and installed McElroy Metal’s 238T symmetrical copper standing seam roofing system the historic structure. Photos: McElroy Metal

“We set up scaffolding and worked on the octagonal cupola first,” Todd says. “The design incorporates a convex curvature with all roof sections meeting at the apex. Together with my superintendent, Diego Trevizo, and our lead foreman, Uri Contreras, we measured everything we needed for the cupola roof and gave the cut list to our shop fabricators, who produced the panels and trim for the cupola roofing, the design of which was proposed by Empire and approved by the Texas Historical Commission and Armko. We also had a 10-foot mechanical brake onsite to fabricate and modify any panels as needed during the installation process. My team and I love working with copper, because aside from the obvious qualities inherent in its chemical makeup, it allows for a more thorough arsenal of seaming and joining techniques due to its unique malleability relative to most other types of commonly used metal components.”

Todd says standing seams were incorporated at each hip of the cupola to avoid the need to solder vertical joints. At the apex of the cupola, standing seams were folded down and lapped under the finial skirt. The crew sealed/riveted/soldered the finial base to the copper panels to create a watertight and wind-resistant detail at this very exposed and relatively flat area.

Standing seams were incorporated at each hip of the cupola. At the apex of the cupola, the seams were folded down and lapped under the finial skirt. Photos: McElroy Metal

Empire Roofing owns roll formers with dies to produce McElroy’s 238T and 138T symmetrical standing seam panels. “Empire’s capabilities with regard to commercial, industrial, and historical roofing projects are far reaching, and we love a good challenge,” Todd says. “If you’ve got a difficult problem, it’s our job to solve it, and we love working with innovative manufacturers like McElroy in doing so.”

Symmetrical standing seam systems do not have male and female legs, but are comprised of panels with matching left and right legs. The panels are joined with a mechanically seamed cap. The panels are non-directional, meaning they can be installed left to right, right to left, or even from the center out. The seam design on a symmetrical panel is more watertight than a double lock because there is no interruption of sealant in the seam at the clip locations. Most importantly, a symmetrical panel can be easily replaced if there is ever damage or a reason to pull a panel out of the roof at a later date.

“Through a judicious use of hydrostatic details utilizing butyl tape in lieu of solder at key areas, we were able to achieve a long-term watertight and wind-resistant roof assembly that only minimally relies on soldered joints and that can accommodate thermal movement much better,” Todd says.

Photos: McElroy Metal

Austin Hall is located on a hill among old-growth trees, so there isn’t much room to park a roll former to produce panels up to 25 feet long. It’s a relatively small project, about 6,000 square feet. “We set up our staging area in the road, about a quarter-mile from Austin Hall,” Todd says. “To minimize disruptions to daily university activities, we decided to run panels in the evening and have 3-4 guys walk the longer panels up the hill, one at a time. We rented a golf cart to transport guys down the hill to the roll former and bring smaller items up to the jobsite. We’ve got a great crew and it was ‘all hands on deck’ for this one. In one night, we produced all the panels and telescoped them to the roof on our spreader bar, which we attached to the forks of our onsite SkyTrack. We didn’t damage a single panel … that’s tough to do with copper.”

Todd was sure the roofing details would be watertight and wanted to make sure the internal gutters didn’t cause any problems. The Empire crew used sandpaper to etch the flat 20-ounce copper before it was fabricated into gutters. Once fabricated and roof-loaded, the gutter pieces were joined in 40- to 50-foot sections in the interior gutter, then lifted out and placed on sawhorses. All joints and seams were fully soldered on the sawhorses and then placed in their respective areas inside the internal gutter troughs, where the few remaining seams were joined and soldered in place. The gutters then were coated with Kemperol 2K PUR, a solvent-free, fleece-reinforced and liquid-applied waterproofing system based in polyurethane resin. Empire used a roller to apply the coating in open areas and brushed on the coating in corners.

TEAM

Building Envelope Consultant: Armko Industries, Austin, Texas, www.armko.com

Roofing Contractor: Empire Roofing, Austin, Texas, www.empireroofing.com

MATERIALS

Metal Roof System: 238T symmetrical copper standing seam roofing system, McElroy Metal, www.mcelroymetal.com

Underlayment: Titanium PSU-30 high-temp self-adhering underlayment, InterWrap, www.interwrap.com

Liquid-Applied Waterproofing System: Kemperol 2K PUR, Kemper System, www.kemper-system.com

Design Combines Modified and Metal Roofs to Achieve Performance and Aesthetic Goals

The new Cumberland County Technical Education Center in Vineland, New Jersey, features a modified bitumen roof system and metal mansards. Photos: Christian Scully/Design Imaging Studios

The original vocational school in New Jersey’s Cumberland County was located in an outlying area many miles from the high schools its students attended, creating transportation challenges for those enrolled. The vocational students would spend the first part of their day at a traditional high school before being transported by bus to the vocational school to participate in specialty courses such as carpentry, electrical, culinary arts and cosmetology, among others. In neighboring Gloucester County, a new model was established that allowed students to fulfill their core curriculum standards at the vocational school while also participating in the specialty courses.

The success of the new model convinced administrators at Cumberland County Technical Education Center (CCTEC) in Vineland, New Jersey, that it was an idea worth exploring. “That new model has really gained traction in New Jersey,” says Bob Garrison, president of Garrison Architects. “Let’s fulfill the core curriculum standards like English, math and science and stop wasting time busing the kids.”

The location chosen for the new school was in a more developed area of the county next to the local community college, increasing accessibility to students. Garrison Architects, who has extensive experience in the New Jersey K-12 and vocational school market, was retained to design the new school. The design team included the architectural firm, school administrators, a representative from the materials manufacturer and members from the state’s department of education.

Design Challenges

The demands of a vocational school and all the equipment required for the various specialty courses provided some design challenges. The shops, located at the back of the school, require a story and a half ceiling height, which differs from the rest of the building. The exhaust fans and other rooftop equipment required for those shops also complicated the design. The original proposed design of a low-sloped roof with parapet wall construction didn’t satisfy the aesthetic goals of school administrators, so they asked the design team to explore the use of a pitched roof. But as Garrison explains, “A pitched roof didn’t work with the width of the building.”

Approximately 187,000 square feet of Garland’s StressPly E FR Mineral modified bitumen membrane was installed as the cap sheet on the low-slope roof. Photos: Christian Scully/Design Imaging Studios

It was ultimately decided that a low-slope modified bitumen roof with metal mansards around the perimeter would achieve both the performance and aesthetic requirements. Garrison worked with The Garland Company, Inc. for the materials as well as help with details, drawings and project inspections. “We needed a company that could provide a high-quality warranted low-sloping system as well as the complementary metal system under one manufacturer,” Garrison says. “That way, the systems are married and it’s warrantable.”

Garland’s StressPly E FR Mineral eco-friendly modified bitumen membrane was installed as the cap sheet on the low-slope sections of the roof. The roof seams were heat welded, providing a seamless appearance across the 187,000-square-foot roof. The metal mansards along the sides and front of the building provide the illusion from the ground that the roof is sloped while also concealing some of the equipment on top of the building. Garland’s R-Mer Span 24-gauge patriot blue steel panels were installed on those mansards. The same panels, some with slopes as steep as 8:12, were used to custom-build the dome atop the clock tower at the main entrance, which serves as a centerpiece of the roof. The metal panels used over the barrel roofs on the gymnasium and cafeteria are continuous, eliminating all possibility of field leaks and contributing to the design the mansards promote.

Just two years after enrolling its first class of students, CCTEC has already developed plans for an expansion that will help accommodate the school’s demand for students focused on a health care path. The proposed 55,000-square-foot, $25 million building will connect directly to the main building via a hallway extension and will accommodate up to 200 students.

About the author: Bill Pancoast has more than 35 years of experience in the commercial roofing industry, providing long-term watertight solutions to a wide range of customers. He is highly knowledgeable in all aspects of the industry, providing his customers with invaluable technical support. He is a territory manager at The Garland Company, Inc.

TEAM

Architect: Garrison Architects, Bellmawr, New Jersey, http://garrisonarch.com

Roofing Contractor: Patriot Roofing Inc., Jobstown, New Jersey, www.patriotroof.com

MATERIALS

Metal Roof System: R-Mer Span, The Garland Company, Inc., www.garlandco.com

Modified Bitumen System: StressPly E FR Mineral, The Garland Company, Inc.

Roof and Walls Are Key to the Design of Lamplighter School’s Innovation Lab

The Lamplighter School’s new Innovation Lab features a standing seam copper roof that transitions to copper wall cladding to wreath the structure in metal. Photo: ©Timothy Hursley

The Lamplighter School is a private school in North Dallas that teaches students from kindergarten through the fourth grade. It features a teaching barn where students learn about animals and an Innovation Lab that spotlights hands-on learning. “It’s a school dedicated to applied learning—the idea of learning by doing,” notes Marlon Blackwell, FAIA, Principal, Marlon Blackwell Architects, Fayetteville, Arkansas.

The campus was originally designed by O’Neill Ford, a well-known regional architect from Texas, and much if it was built in the 1970s. The school recently reached out to Marlon Blackwell Architects to conduct a series of interventions with some existing buildings and design some additions, including the new Innovation Lab and teaching barn. Part of the overall focus was to help smooth out the traffic flow on the campus. The new 10,000-square-foot Innovation Lab would be in a crucial location, and its roof and wall designs would become instrumental in helping the structure meet its design goals.

“The Innovation Lab we conceived of as a way of reinforcing the center of campus and acting as a connector to other parts of campus,” Blackwell says. “It has a series of porches that act as connectors and also control places for kids to play and learn outside.”

Photo: ©Timothy Hursley

The school administrators wanted a one-story building, and they wanted it to relate to the original architecture of the campus without replicating it too closely. According to Blackwell, the roof was a key component in the design for several reasons.

First of all, the uniquely shaped roof helps define the spaces within the building. “They had a very disparate program,” he explains. “They had science, environmental science, shop, robotics, and a cooking/teaching kitchen — they had a variety of different spaces. We thought we could take the roof and pitch and roll it to scale those spaces — some grand spaces, some smaller. It would be a continuous, folded roof that’s copper on the outside, and that roof would become the envelope as well. So, we wanted timeless materials, and there were already a few copper roofs on the campus, so it was tying into it materially.”

The roof is comprised of standing seam and flat copper panels, while the wall cladding consists of copper flush panels. Carlisle Water & Ice Protection was specified for the roof to serve as a secondary water barrier. Second-growth Cypress planks were used to complement the copper in the porch areas. “So that’s where the material palette and the copper came from, and of course the workability of copper made a lot of sense with this type of roof as well.”

Copper over ice and water shield is a very durable assembly, notes Blackwell. “The whole building is wrapped in copper, and we let the roof do what it does, which is very different, because you’re creating valleys more than ridges, which is a bit unusual for a roof,” he says. “We tried to create really nice spaces for the kids. We wanted lots of natural light and windows to provide controlled views of the landscape and the campus around it. The Innovation Lab really has become a kind of a feature for the campus.”

A Challenging Project

Controlling the water flow on the roof would become one of the biggest challenges on the project. The roof makes use of both internal and external drains, with hidden downspouts at the perimeter. “What we invented in the process of developing the drainage system was using sections of the cladding as actual downspouts,” says Blackwell.

The roof was shaped to define spaces within that house different programs, including environmental science, shop, robotics, and a teaching kitchen. Photo: ©Timothy Hursley

The cladding was approximately 2 inches deep, so the downspouts could be integrated behind the copper wall panels. “You might have a downspout that’s 2 inches by 18 inches, for example, and we just integrated that into the envelope so it’s seamless. You don’t see any gutters or downspouts, and those go directly into the subsurface drainage.”

The general contractor on the project was Hill & Wilkinson of Richardson, Texas. Copper panels were roll-formed and installed by Sterling Roof Systems of Garland, Texas. “They rolled the panels on site, and because of that we could make these downspouts integral to the cladding and have that seamless look,” Blackwell says. “The roof is standing seam, and the vertical walls are butt-jointed, interlocking flat panels, and those work together very well. We also had some big, copper fascias and the installer did a really nice job with that. Overall, it’s a really a great, durable envelope or wrapper for the building.”

Properly integrating the roof and wall systems was crucial. “Making that transition between the vertical and the horizontal was key, and thanks to the workability of the copper you could make clean, crisp, simple details,” Blackwell says. “Otherwise, it is a pretty straightforward system.”

Marlon Blackwell Architects also developed landscape perimeters and boundaries that complement the structure and help control traffic.

The project won a 2019 North American Copper in Architecture Award from the Copper Development Association, which recognizes and promotes North American building projects for their outstanding use of architectural copper and copper alloys.

Cypress planks complement the copper envelope at the porch areas, which were designed to help channel foot traffic at the campus. Photo: ©Timothy Hursley

The timelessness of copper is part of its appeal, according to Blackwell. “The patina of copper is lovely,” he says. “Over time it becomes a real leathery brown with a little plum in it even. The way in which it ages is really beautiful, and it’s dynamic, and that’s what we like about it, too. It ages differently depending on the orientation or the elevation. It’s just a really great system.”

Architects at Blackwell’s firm are drawn to metals like copper, zinc and CorTen. “We use a lot of metal siding and roofs, and we love these raw metals, these caustic metals that respond to the environment,” Blackwell says. “They have a dynamic surface that’s in constant change, so the building is really never finished, right? The weathering constructs the finish on these buildings, and we love that because it has its own romance. It makes the building distinctive and unique.”

TEAM

Architect: Marlon Blackwell Architects, Fayetteville, Arkansas, www.marlonblackwell.com

General Contractor: Hill & Wilkinson, Richardson, Texas, www.hill-wilkinson.com

Roofing and Sheet Metal Contractor: Sterling Roof Systems, https://sterlingrooftexas.com

MATERIALS

Roof Panels: Standing seam and flat 16-ounce copper panels, 16-inch exposure

Wall Panels: Copper flush panels, 8-inch exposure

Underlayment: Carlisle Water & Ice Protection, Carlisle WIP Products, www.carlislewipproducts.com

Talented Team Helps School District Get the Most Out of Its Roof Assets

Roofs in the Milwaukee School District are inspected annually and undergo a five-year cyclic maintenance program. Photos: Atlas Roofing Corporation

When Dennis Fula took over the roofing shop for the Milwaukee Public School District more than 20 years ago, many of the school’s roofs were failing, and some buildings were in danger of being condemned. He reached out to a manufacturer to help him institute a program to inspect and prioritize roof repairs and replacements — and set up specifications to ensure the roofs he installed would last longer and need fewer repairs.

Today, Dennis Fula’s son, Ryan Fula, is now in charge of the roofing shop at Milwaukee Public Schools (MPS), and he’s realizing the benefits of the program his father helped set up more than two decades ago.

The Milwaukee Public Schools facilities management team includes (from left) John Linn, MPS Manager of Design and Construction; Dennis Fula, the previous crew leader of the MPS roofing shop; and Ryan Fula, the current crew leader. Photos: Atlas Roofing Corporation

According to Ryan Fula, his father teamed up with Dan Dalle Nogare, an independent representative of Atlas Roofing Corporation, to address the school district’s roofing issues some 23 years ago. The pair convinced the school system to adopt a comprehensive program to evaluate and maintain the district’s roofs. A key part of the plan was the implementation of theAtlas Roofing Corporation Certified Drainage Program (CDP), a low-slope tapered insulation design service that focuses on eliminating ponding water on a roof’s surface to extend the service life of the system.

“Atlas Roofing came in and did a presentation on how they can save money in the long run working with Milwaukee Public Schools by offering the Certified Drainage Program,” Ryan Fula recalls. “So, we decided to take a shot at it and see how it might work out.”

When it is time for a roof replacement, the specifications call for using tapered insulation designed by the team at Atlas Roofing’s Certified Drainage Program to ensure proper drainage. Photos: Atlas Roofing Corporation

According to Fula, the results over the last two decades have been impressive. “It’s been working out great ever since,” he says. “It helps us with the budget, it’s paying off now, and it will continue to pay off into the future.”

The program has been embraced by the school district, the roof system manufacturer, and the contractors who work on the projects. Ryan Fula and others currently involved with the program — most of whom represent the second generation of employees at their companies working under the arrangement — shared their insights on how the program works and why it’s effective. All of them cited it as a role model for other school districts across the country to follow.

The School District

According to Ryan Fula, Milwaukee Public Schools encompasses more than 160 buildings with approximately 9 million square feet of roofing. The first priority of Fula and his roofing team is to fix and repair leaks, but their overall strategy involves taking a long-term approach to managing roof assets. The MPS roofing crew conducts annual inspections of each roof, and crew members clean up debris and check for problems. Every summer, the team conducts a five-year cyclic review, which includes routine maintenance, repairs, cleaning roofs and sometimes applying an aluminum roof coating. After 25 years of service, each roof is fully evaluated.

“We’re all about planning for the future and preventative maintenance,” Fula says. Most of the roofs in the school district are BUR or modified bitumen systems. “We like to keep our roofs smooth,” Fula notes. “As a rule, we don’t like gravel or ballast. The reason why is we only have four employees, and with the amount of square footage we have we don’t have time to spud or remove ballast.”

The roof on the 88thSt. School was replaced with a modified bitumen system utilizing plan tapered insulation with a four-way slope. Photos: Atlas Roofing Corporation

Each year, Fula goes over his list and determines which roofs need to be repaired or replaced. When a building needs a full roof replacement, the process works like this: The Atlas representative visits the project, meets with Fula, and takes field measurements. The CDP team puts together a budget and preliminary plan, and the project is sent out for bid. Once the job is awarded, the contractor chosen removes the existing roof system and installs a temporary roof to keep the building watertight. The rep then conducts a detailed auto-level survey that maps out the entire deck, recording any deck deflection and high and low areas. Then the team at CDP comes up with a tapered insulation plan to ensure proper drainage.

Fula is involved at every stage of the process and serves as the construction liaison to the administrators and teachers at the school. “I work directly with the schools and the construction contractor from start to finish as the roofing work takes place,” Fula says. “I’ll be the inspector on the job. I’m there on a daily basis. Our biggest priority is to make sure that we don’t disrupt the school.”

The Rep

One of the first people Fula contacts when it’s time for a roof replacement is Brett Kaehler, his Atlas representative. Kaehler works at Adroit Marketing Inc., headquartered in Slinger, Wisconsin, which has represented Atlas since 1988. Working alongside Dan Dalle Nogare, who helped launch the program, Kaehler has worked on more than 20 projects with MPS.

Consultation typically begins in the budgeting stage. “If a roof needs a full replacement, they would already have plans for that roof, so we would go out and field measure the roof to verify the overall measurements, noting any penetrations or drains,” Kaehler says. “We field verify everything and send that report down to our tapered team in Atlanta.”

Six contractors are approved to bid on MPS projects, and they receive the preliminary roof plans and scope of work to help them prepare their bids. Once the job is awarded, the tear-off process begins. After the tear-off is complete and a temporary roof is installed, Kaehler meets with Fula to conduct the auto-level survey of the roof. “We grid out the roof in either 12-foot or 8-foot sections,” Kaehler explains. “We shoot heights in each individual quadrant. If there are areas of concern with low spots, we might even tighten it up to a 6-foot or 4-foot grid. We take pictures and include those with the heights in our report to CDP.”

The reports are turned around very quickly, notes Kaehler; the final plans are usually received within two days. The tapered insulation plan is logical and easy to follow, even for a new contractor, according to Kaehler. “It’s like a puzzle,” he says. “We give you the layout and tell you where to place each puzzle piece. It’s pretty cut and dried. There is minimal waste. We try to keep it as simple as possible.”

Every member of the team has the same end goal in mind. “At the end of the day, we want a perfectly pitched roof for Milwaukee Public Schools for their longevity,” Kaehler says. “We want the contractor’s name to be well represented. We want Atlas Roofing’s name to be well represented. It’s a complex process, but we have it so fine-tuned it doesn’t seem so complex. We all know it and understand it very well. There are a lot of moving parts, but it moves very smoothly. It’s a well-oiled machine.”

Kaehler commends Milwaukee Public Schools for their proactive approach. “They do a great job with preventative maintenance,” he says. “Sometimes with an owner, a roof will be out of sight, out of mind — they won’t look at it until it is leaking. Milwaukee Public Schools doesn’t look at it that way. If something does come up, they nip it in the bud before it becomes a problem.”

Kaehler monitors the project through completion and conducts a final inspection. “I’m on the site regularly,” he says. “We do a roof inspection to make sure everything is draining properly, preferably after a good rain to ensure there is no ponding water.”

The Tapered Design Team

Shaun Kerschen is the director of Private Label and Tapered Services for Atlas Roofing, based in Atlanta, Georgia. He joined the company in 2002 and began designing tapered polyiso insulation systems for commercial projects in 2003. Some of his first projects were for the Certified Drainage Programon MPS buildings. He’s since been promoted to oversee the tapered insulation design team, which has four full-time designers, including Jennifer Tyree, who has handled MPS projects since 2008. “We review the plan sets and work up quotes for tapered insulation systems,” Kerschen notes. “After the project is sent out for bid and the job is awarded, we work up shop drawings and installation plans. The material is delivered to the jobsite and installed by the contractor.”

Measuring the actual roof deck is critical, notes Kerschen, as there can be surprises that emerge as the tear-off is executed, especially on older buildings. “Over the last 16 years I’ve seen some pretty crazy things,” he says. “On one section of roof that had been involved in several additions over the years, we found five different deck heights. We had to fill in several sections with insulation before we could even begin to install the taper.”

The tapered insulation plan has some typical design requirements. “As part of the certification process, we agree to provide a tapered insulation system to provide positive drainage and void substantial ponding water within 24 hours,” says Kerschen. “The system has to be designed with four-way slope. We do not allow two-way slope with saddles or crickets, except in very unusual circumstances. The minimum requirement is a 3/16 inch per foot slope; that allows us to correct a lot of issues. In some cases, we will require 1/4 inch per foot slope.”

Once the tear-off is executed, the final plan must be completed very quickly, according to Tyree, but the detailed reports and advance planning help speed the process. “The reps are my eyes in the field,” Tyree says. “They’ll identify the drains and anything that might be an issue. They’ll point out anything I need to know, such as height issues on windows, for example. Then I work up the plan. The biggest thing is to take meticulous notes, keep everything organized, and turn it around very quickly when the time comes.”

Everyone on the team knows their part in the process, notes Tyree. “The goal is putting on a good roof that lasts, with quality workmanship from certified contractors,” she says. “Our reps are out there, hands-on, from the very beginning. They check how the roof performs after a rain. We provide more peace of mind for the owner.”

The Contractor

The program also makes life easier for the installing contractor, notes Doug Biggar, project manager for Langer Roofing & Sheet Metal Inc., a union-affiliated commercial roofing contractor headquartered in Milwaukee.Langer Roofing is one of the companies approved to work on MPS projects. Biggar took over as the point man on MPS projects after the retirement of Dave Novak a few years ago, and he is another admirer of the smooth-running system his predecessors put in place.

“The biggest benefit of the Certified Drainage Program is that it provides a higher-quality product in the end,” Biggar says. “It’s a great team, and it also makes it easier when you are working with a more involved owner. If we are working over an occupied building, I don’t have to sit down and explain everything to the principal; that’s all handled by the MPS people. We have one point of contact, and it’s Ryan. Every day our foreman connects with Ryan at the beginning of the day and they go over the plan. Ryan lets the principals and the teachers know what’s going on. It makes our lives so much easier.”

The plans from CDP ensure the quality and longevity of the system, and the communication of every member of the team saves the contractor time and minimizes confusion. “Ultimately, it’s a higher-quality product, and the process streamlines things,” Biggar explains. “When the roof is put on, we don’t have punch-list items, and we don’t have ponding water.”

Biggar credits his company’s experience and union training as the keys to quality workmanship. “It’s a great team from top to bottom,” he says. “We’re a union shop, so we are all well trained. I have the ability to sell any type of system, any type of service work. We’re certified with every major manufacturer out there. It all boils down to the ability of our guys in the field and our equipment. We have a full-time safety director. There are a lot of years of experience in our project management team. We do things right around here.”

Investment Pays Off

According to Fula, the investment in the roof asset management program is paying big dividends. The team effort helps ensure the roofs meet their maximum life cycle while minimizing emergency repairs. Fula’s advice for other school districts is to determine the full life-cycle cost of a roof system — not just the initial cost.

“We are making the investment up front,” he says. “When these roofs are coming around to be replaced, we are completely ripping them off down to the deck. We’re installing a vapor barrier. Atlas will come in with the Certified Drainage Program, and they will guarantee that the water will be off our roof in 24 hours. So now we are energy efficient, we are up to code, but we also have the guarantee that the water is gone. If we do have a leak, we won’t have standing water there to cause further damage to the system.”

“Ponding water is the number one cause of problems for low-slope roofs,” notes Fula, “so making sure the roofs have proper drainage is critical.” He has seen the proof with his own eyes.

“Now, with the Certified Drainage Program in place, we are really able to see how the roofs are doing and how our investment is paying off there,” Fula says. “The roofs we designed and installed are lasting longer. In the past, just about every 25-year-old roof was put into our deferred maintenance program to be repaired or replaced. Now I’m looking at 20-year-old roofs, and they look brand new.”

Metal Panels Illuminate Institute for Contemporary Art at VCU

The exterior of the Institute for Contemporary Art features 28,000 square feet of zinc roof and wall panels. Photos: Rheinzink

The Institute for Contemporary Art (ICA) at Virginia Commonwealth University (VCU) will bring the most important, cutting-edge contemporary art exhibits in the world to the VCU campus and the city of Richmond. Located in the striking new Markel Center and designed by architect Steven Holl, the ICA offers 41,000 square feet of flexible space including a 33-foot-high central forum. The ICA features a dynamic slate of changing exhibitions, performances, files and interdisciplinary programs.

“We designed the ICA to be a flexible, forward-looking instrument that will both illuminate and serve as a catalyst for the transformative possibilities of contemporary art,” Steven Holl says. “The fluidity of the design allows for experimentation and will encourage new ways to display and present art that will capitalize on the ingenuity and creativity apparent throughout the VCU campus.”

In keeping with VCU’s master sustainability plan, the ICA incorporates state-of-the-art technologies and environmentally conscious design elements and makes use of numerous natural resources.

The exterior for the contemporary design features 28,000 square feet of Rheinzink roof and wall panels. According to Steven Holl Architects, “The prePATINA blue-grey Rheinzink exterior interfaces with clear and translucent glass walls and skylights that infuse the building with natural light and lessen reliance on nonrenewable energy. The zinc shares the same greenish-gray tonality as the matte glass, giving the building a shifting presence from monolithic opaque to multifarious translucent depending on the light.”

The Rheinzink panels were custom fabricated A. Zahner Company. They were installed by Kalkreuth Roofing and Sheet Metal. Photos: Rheinzink

The custom cassette panels were designed and fabricated by Rheinzink systems partner A. Zahner Company, Kansas City, Missouri, and installed by Kalkreuth Roofing and Sheet Metal, Wheeling, West Virginia.

The open joint metal panel rain screen system utilized 1.75-mm zinc. According to Zahner project manager John Owens, “The 1.75-mm zinc is a little heavier than normal but that’s what the architect wanted.” Zahner provided 1,200 total panels, of which 200 were curved. “We cut those panels radially as needed to fit the curved aluminum frame. All of that fabrication was done in our shop.”

Gary Davis, Zahner’s director of marketing, added, “We developed multiple panel systems using Rheinzink materials on a supply-only basis. To create museum-quality edges and detailing, Zahner digitally defined the scopes of work and fabricated from our 3-D model. Preceding construction tolerances were dealt with in a timely manner.”

TEAM

Architect: Steven Holl Architects, New York, www.stevenholl.com
Roofing Contractor: Kalkreuth Roofing and Sheet Metal, Wheeling, West Virginia, www.krsm.net
Metal Fabricator: A. Zahner Company, Kansas City, Missouri, www.azahner.com

MATERIALS

Zinc Roof and Wall Panels: 1.75-mm prePATINA zinc, Rheinzink, www.rheinzink.us

Iconic Structure at Utah State Gets New Roof Over Summer Breaks

The roof on Utah State University’s iconic Old Main structure was replaced over the course of three summers by the team at KBR Roofing. Photos: Davinci Roofscapes

There was no summer break for the team at KBR Roofing these past three years. As soon as school ended in May for students at Utah State University, the team got to work on re-roofing the iconic Old Main structure on campus.

Originally built in 1889, Old Main has served its community for more than 125 years. Now listed on the National Register of Historic Sites, the imposing structure is home to the president of the university and a multitude of offices and classrooms.

“Every summer we tackled a different phase of the re-roofing project,” says Brent Wood, project manager at KBR Roofing. “This structure is so critical to the university that it made complete sense to invest in composite roofing. The old, curling gray wood shingles simply had to come off.”

Each summer, the crews from KBR Roofing focused on a different element of the project. “We encountered a few challenges along the way,” Wood notes. “First, since the structure was built so long ago, many of the walls were not square. Second, due to a fire on the north side in 1984, this section of the roof had to be re-sheeted. Third, we had to fabricate four new cupolas. And fourth, we had to custom create a pedestrian bridge 106 feet on top of the center to access the east tower.”

With all their challenges, Wood relates that the easiest part of the project was installing the DaVinci Roofscapes Fancy Shake tiles. “We used the regular shake on the roof surface and then the beaver tail and diamond tiles to accent different parts of the structure,” Wood says. “They were a dream to install.”

Passing Historical Review

Before installation began, representatives of Utah State University and Design West Architects sought permission to use the composite shake tiles on the Old Main project.

Originally built in 1889, Old Main is listed on the National Register of Historic Sites. The building houses the president of the university and a multitude of offices and classrooms. Photos: Davinci Roofscapes

“USU has an on-campus architectural review committee that monitors and approves all changes to buildings, signage and landscaping,” says Quin E. Whitaker, PE MBA, structural engineer/project manager at Utah State University. “Our Facilities team was required to meet with the State Historical Department of Utah to gain approval of the Fancy Shake shingles. When we met with the state’s representative, he declined all proposed roofing samples, including one from DaVinci. We asked him to go look at the DaVinci tiles installed on our Geology building back in 2012. As soon as we got there, he immediately told us the composite tiles looked great and met his expectations.”

Getting approval was critical, notes Whitaker. “Old Main is our flagship building,” he says. “It houses the president of the university, her staff and many other administration officials and classrooms. We didn’t wish to skimp on the quality of this roofing product. Gaining approval on the DaVinci product was especially important since we anticipate that five historic buildings on the campus quad (including Old Main) will all have the same composite roofing tiles installed in the coming years. The DaVinci product has an authentic look, backed by a strong warranty, which we appreciate.”

Going the Extra Mile

With the green light received, KBR Roofing started the Old Main roofing project in May of 2015. At the same time, the roof specialists from the university’s carpentry shop created new cupola bases.

“Bryan Bingham and Mike McBride at our university were intimately involved in the project,” says Whitaker. “I’ve never seen the level of craftsmanship that they were able to achieve for the cupola bases. Everyone involved in this project gave 110 percent.”

A cupola on the backside of the structure features beaver tail tiles. Photos: Davinci Roofscapes. Photos: Davinci Roofscapes

Going the extra mile involved quite a few special considerations for KBR Roofing on this project. The team manufactured a 15-foot pedestrian bridge to allow access from the roof to one of the towers. Located more than 100 feet in the air, the new bridge complements the building’s structure and meets code requirements.

On the north side of the building, workers crafted new metal sheeting on four finials. At the south tower, the stone finials were in need of renovation. The roofers contracted with Abstract Masonry to revitalize the stone, mortar joints and other surrounding brick features. They also contracted with Rocky Mountain Snow Guards for snow fences and snow guards that were installed around the entire structure. Drift II – two-pipe snow fences were put in place at the eaves over pedestrian and vehicular areas as a barrier to snow movement with RG 16 snow guards applied in a pattern above to hold the snow slab in place.

“Three of Old Main’s four towers now have a new DaVinci roof on them covered with the company’s attractive diamond shingles,” says Whitaker. “KBR Roofing was amazing. They also had to radius the railing for the two large rotundas. This company, in my estimation, is top notch and the only company that could have pulled off this project.”

TEAM

Architect: Design West Architects, Logan, Utah, www.designwestarchitects.com
Roofing Contractor: KBR Roofing, Ogden, Utah, www.kbrroofing.com

MATERIALS

Composite Shingles: Fancy Shake composite cedar tiles, DaVinci Roofscapes, www.davinciroofscapes.com
Snow Guards: Drift II and RG 16, Rocky Mountain Snow Guards, www.rockymountainsnowguards.com

Meticulous Preparation Sets Up Restoration Project for Success

Photos: Debby Amador, Roma Police Department

Officials at Roma High School in Roma, Texas, knew they needed a new roof. The tile roof on the main complex was more than 25 years old, and some components were clearly failing. They didn’t realize that many of the leaks and resulting wall deterioration were caused by other problems as well. Luckily, they reached out to design and construction professionals who did their homework, diagnosed all of the key problems, and developed a plan to fix them. The crowning touch of the building envelope restoration plan was a beautiful standing seam metal roof, and the success of the project is proof that hard work pays off not only in the classroom, but on top of it.

The Consultant

As its building envelope consultant, Roma Independent School District chose Amtech Solutions Inc., headquartered in Dallas, Texas. The full-service architectural, engineering, and building envelope consulting firm has been in business since 1982. Working out of the company’s Rio Grand Valley (RGV) office located in Pharr, Texas, Amtech Solutions inspected and evaluated the entire site and reviewed legacy documents to identify the underlying issues.

They found quite a few, notes Michael Hovar, AIA, RRO, LEED AP, a senior architect and the general manager of the company’s RGV office. “They thought all they had was a roofing problem,” he notes. “But we saw right away that not properly managing water off the roof was the cause of wall deterioration, which then became leaks into the building. Our experience with the entire envelope and all facets of design and construction really helped us on this one.”

Roma High School in Roma, Texas, underwent a three-phase building envelope restoration plan in 2016-2017. After the walls were repaired and restored, the roof and mechanical equipemt were replaced. Photos: Debby Amador, Roma Police Department

Amtech Solutions put together a presentation for the school board to detail what they discovered and the plan they proposed to remedy the situation. The company also worked with the school district to help develop a budget.
The restoration plan was split up into three phases. The first phase focused on restoring the walls and windows. The second phase encompassed roof replacement and installing new mechanical equipment. The third phase involved improving drainage, grading and other site repairs.

Amtech Solutions decided not to bid the project out to a general contractor, but rather to bid each phase separately. “We decided to split it up into stages and do it logically, starting with the walls first,” Hovar says. “For the walls, we got restoration contractors who specialize in wall restoration work.”

Restoration Services Inc. (RSI) of Houston, Texas handled the first phase in the summer, as the wall repairs would be louder and more disruptive to students. The roof replacement project was scheduled for the fall. “Once all of the stuff on the ground was done, that allowed us to do the re-roofing work throughout the school year, which also helped the price,” notes Hovar. “Our experience has always been that if we have good cooperation with the contractors and the school staff, at the end of the job they end up being best friends. And that’s exactly what happened. At the end of the job, they were sad to see the roofers go.”

Amtech Solutions convinced the school district the plan would work. “It took some coordination, communication and cooperation, and it took a motivated owner that was willing to do this and trust us,” Hovar says. “They looked to us for guidance, and we said, ‘We do this all the time. We do roofing projects throughout the year, occupied and unoccupied, and we do it in a way that respects what the occupant’s needs are.’”

When it came time to specify the roof system, school board members were divided; one faction wanted to install a new tile roof, and the other wanted to go with metal. “The interesting thing is, for the historical architecture of the area, both of those roofs are appropriate, so from the standpoint of historical significance, either one works,” Hovar says. “In the end, it was quite a bit more expensive to utilize tile than it was to utilize a metal roof.”

The Roof Systems

The decision was made to go with a standing seam metal roof from McElroy Metal on the vast majority of the complex, including the main roof, the gymnasium, and two freestanding structures — the art and industrial arts buildings — that had been added over the years. The main tile roof was removed and replaced with McElroy’s 138T Panel, a 16-inch-wide, 24-gauge panel in Brite Red. McElroy’s 238T Panel, a 24-inch-wide, 24-gauge panel, was specified for the gym, as well as the art and industrial arts buildings. In a cost-saving measure, the color on the gym roof was changes to Galvalume Plus. In all, more than 233,000 square feet of metal roofing was installed.

Before

“The reason we picked this roof system is we’ve had a lot of great experience with it,” Hovar says. “We love that panel because they can actually bring the roll former to the jobsite. That gives the roofing contractor a lot more options on how he can load the roof and sequence the job. The other beauty of this panel is that it has unlimited movement. The panels itself slides back and forth over a fixed clip. It also flashes like a dream.”

Low-slope roof areas adjacent to the gym were replaced with a two-ply modified bitumen system from Siplast. CPI Daylighting manufactured a new skylight for the atrium.

As part of the roofing phase, gutters and downspouts were added. “There was nothing controlling the water before on this project,” Hovar says. “We designed a gutter system with expansion joints as per SMACNA guidelines. The contractor made absolutely beautiful shop-welded aluminum downspout boots.”

The most crucial detail was a custom-made saddle that solved the problem of water infiltration at the transition between the roof and walls on the wings. “This ultimately simple solution addressed one of the major design flaws that plagued the facility from the first days of occupancy,” Hovar notes. “We modeled the three-dimensional design of those saddles, and the contractor welded them in his shop. He fabricated them out of .080 aluminum and they were seamless. The restoration contractor had already installed all of the through-wall flashing, so all the roofer had to do was put counterflashing in and do his work around it. He was able to fly without being slowed down by a mason on the job.”

The Roofing Contractor

The roofing phase of the project was handled by Rio Roofing, headquartered in Harlingen, Texas. The company primarily installs low-slope and metal roofs, and its focus is on large commercial and institutional projects. ““We do nearly 90 percent public bonded work,” notes Hedley Hichens, vice president of Rio Roofing. “We found out that whether it’s a small job or a big job, the paperwork is still the same, so we try to make it worthwhile.”

The company worked on the Roma High School project for about a year, wrapping up the roofing phase of the project in November 2017.

After the structure’s main roof was removed, the tile was replaced with a standing seam metal roof featuring McElroy’s 138T Panel in Brite Red. Photos: Debby Amador, Roma Police Department

The decision was made to tackle the wings on the main roof first. “During the pre-con meetings, we met with the principal and the superintendent and asked, ‘Which wings are the worst?’” Hichens notes. “There was one wing that was the most problematic, so we started with that area first.”

Rio Roofing began by tearing off the existing tile roof. “There were about 1,925 squares of concrete tile we had to remove,” Hichens notes. “We had crews on the roof tearing off tile, crews on the ground palletizing the tile and storing it in the parking lot.”

As crew members removed the old tile and felt, others followed behind and installed polyisocyanurate insulation and Polystick MTS, a waterproofing underlayment designed for high-temperature applications. “We did 40 or 50 squares a day, moving down the wing,” Hichens says. “We dried in the whole school. Then we came back with the 138 panel.”

On top of the gym and other buildings that received the 238T panel, the existing metal roofs were left in place. “We put flute fill on top of the old panels. Then we screwed down 3/8-inch Securock, primed it and put the Polyglass underlayment down on top of that,” Hichens explains. “That 24-inch panel is a great panel to work with because every time you put one down, you’re 2 feet closer to finishing.”

Installing the New Roofs

The school’s main roof covers a central hub with eight wings coming off of its octagonal skylight. Where the wings tie together, access was limited.

“It was a tight squeeze,” Hichens says. “Getting in there and getting out was difficult. I think our fork lift only cleared one of the walkways by 2 or 3 inches. It’s a big campus, but the layout was difficult at the school.”

Once the wings were dried in, sheet metal crews installed the edge metal and 4,000 linear feet of gutters. They also started forming the panels.

Typically, Rio Roofing lifts the roll former to the roof edge, but it was difficult to get a large lift next to the building, so in this case the roll former was left on the ground. It was moved from wing to wing as the job progressed. “We used a New Tech roll former on this project,” Hichens says, “We would put the roll former parallel to each wing and store the panels on the ground in each area.”

Panels were hemmed and notched using a Swenson Snap Table Pro and lifted to the roof with a fork lift and a special cradle. Crews used a hand seamer to set temporary seams and followed up with a robotic seamer from D.I. Roof Seamers. “The panels are easy to install,” Hichens says. “You get about four guys 10 feet apart to engage the panels and clips and you just keep going. At the end of the day crews put the seam caps on.”

On the low-slope areas, Rio Roofing installed approximately 47,000 square feet of the Siplast two-ply SBS modified system, which was torched down over new lightweight concrete. “For their size, the low-slope areas had a ton of mechanical equipment and ductwork up there,” notes Hichens. “There were a lot of key details.”

Rio Roofing custom-manufactured numerous curbs and details, including the saddles over problem areas at the walls. “We have a full welding shop,” Hichens notes. “We have a full machine shop. We make all of our own curbs here, so there is no lead time for ordering curbs, and we are sure they’ll fit.”

Teamwork

Work on the project has now moved on to a fourth phase: installing translucent panels over the swimming pool. Hovar believes teamwork was the key to the project’s success. “We had such a good contracting team, we did good field work to begin with, and we had an understanding owner,” he says. “Designing it wasn’t easy, but thankfully our experience helped. We just had a really good team to execute it, all the way around. That’s what makes for a great, project, right? When everybody is invested in a good outcome, they always support everybody else.”

Communication was also essential, and Building Information Modeling (BIM) helped keep everyone on the same page. “We modeled the project on our BIM software, and it helped everyone understand the scope and challenges. The BIM model allowed the owner see exactly what the project would look like, and it helped the contractor understand the staging and logistical challenges before the project was bid,” Hovar says. “There were no surprises.”

TEAM

Architect and Consultant: Amtech Solutions Inc., Pharr, Texas, www.amtechsls.com
Roofing Contractor: Rio Roofing, Harlingen Texas
Wall Restoration Contractor: RSI-Restoration Services Inc., Houston, Texas, www.rsi-restorationservices.com

MATERIALS

Metal Roof System
Metal Panels: 138T panel (16 inches wide, 24 gauge) and 238T Panel (24 inches wide, 24 gauge), McElroy Metal, www.mcelroymetal.com
Underlayment: Polystick MTS, Polyglass, www.polyglass.us
Cover Board: Securock, USG, www.usg.com
Skylight: CPI Daylighting, www.cpidaylighting.com

Low-Slope Roof System
Modified Bitumen Membrane: Paradiene SBS, Siplast, www.siplast.com
